Vishay Thyristor SCR 1 kV 16 A 60 mA Gate Trigger Current 360 A Surge Current VS-16RIA100

Free Delivery in India | Lowest Global Shipping Charges

Vishay Thyristor SCR 1 kV 16 A 60 mA Gate Trigger Current 360 A Surge Current VS-16RIA100

Name: Vishay Thyristor SCR 1 kV 16 A 60 mA Gate Trigger Current 360 A Surge Current VS-16RIA100
Brand: Vishay
SKU: 182922
Price: 27.8 USD
Availability: InStock



Category Thyristor Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Model	VS-16RIA100
Mount Type	Screw
Series	VS-16RIA
Maximum Operating Temperature	125°C
Package Type	TO-48
Minimum Operating Temperature	-65°C
Pin Count	2
Rated Average On-State Current Irms	16A
Thyristor Type	SCR
Repetitive Peak Reverse Voltage VDRM	1kV
Surge Current Rating	360A
Maximum Gate Trigger Current Igt	60mA
Maximum Holding Current Ih	130mA
Maximum Gate Trigger Voltage Vgt	2V
Peak On-State Voltage	1.75V
Repetitive Peak Off-State Current	10mA

Key Features

Operates with maximum gate trigger current of 60 mA for precise activation.
Surge current rating reaches 360 A ensuring durability under sudden load.
Equipped with TO-48 package and suitable for screw mounting.
Features a maximum holding current of 130 mA for stable conduction.
Designed for operating temperatures from -65°C to 125°C.
Two-pin configuration compatible with standard circuit designs.
Peak on-state voltage of 1.75 V for minimal power loss.
Offers repetitive peak reverse voltage of 1 kV for high voltage endurance.

Product Description

Vishay VS-16RIA100 Thyristor SCR is an industrial-grade discrete semiconductor device designed for efficient phase control applications in power electronics. It supports a rated average on-state current of 16 A and a repetitive peak reverse voltage of 1 kV, suitable for reliable switching under demanding electrical conditions. The device is housed in a TO-48 package with a screw mount type, ensuring ease of installation in various systems.

The VS-16RIA100 has a surge current rating of 360 A, enabling it to withstand intense transient currents encountered during switching operations. Its maximum gate trigger current is 60 mA with a trigger voltage up to 2 V, allowing precise gate control. The holding current is rated at 130 mA, maintaining conduction stability across voltage ranges.

Environmental specifications ensure operation within a wide temperature range from -65°C to 125°C, making it reliable for industrial, laboratory, and manufacturing equipment applications such as battery chargers, welders, and regulated power supplies.

With its two-pin design, this SCR functions as a solid-state switch with four alternating semiconductor layers to control high power loads with minimal losses, registering a peak on-state voltage of 1.75 V. It does not conform to automotive standards and is not RoHS certified.

Operates reliably in industrial and power control equipment. Suitable for applications in welders, plating equipment, and temperature/speed control circuits. Encapsulated modules provide electrically isolated base plates for enhanced safety.

Facilitates efficient production processes by ready insertion into machinery. Compact and robust TO-48 package ensuring durability.

This Vishay thyristor is a key component when high-performance semiconductor switching devices are needed in electronics manufacturing, HVAC controls, and power supply regulation tasks.
