KEMET C4C Film Capacitor ±5 % Tolerance 33 nF 3 kV DC 750 V AC Through Hole Mount C4CAYUC2330AA0J
Specifications
| Country of Origin | India |
|---|---|
| Brand | KEMET |
| Height | 20.5mm |
| Length | 33mm |
| Model | C4CAYUC2330AA0J |
| Packaging | Bag |
| Width | 20.5mm |
| Mount Type | Through Hole |
| Series | C4C |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±5 % |
| Capacitance | 33nF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Wire |
| Dissipation Factor | 0.0005% |
| Lead Length | 6mm |
| Standards/Approvals | EN 61071, IEC 61071, VDE 0560 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 750V ac |
| Rated DC Voltage | 3kV dc |
| Lead Diameter | 1mm |
| Equivalent Series Resistance ESR | 28mΩ |
Key Features
- Polypropylene film dielectric provides low losses and high ripple current capability.
- Rated AC voltage of 750 V and DC voltage rating of 3 kV ensures reliable operation.
- Through hole type mounting with wire terminal and 6 mm lead length.
- Operating temperature range from -40°C to 85°C suitable for industrial environments.
- Low Equivalent Series Resistance of 28 mΩ reduces heat generation and increases efficiency.
- Dissipation factor of 0.0005 % ensures minimal power loss in circuits.
- Plastic packaging in bag form for safe transportation and storage.
Product Description
The KEMET C4CAYUC2330AA0J film capacitor from the C4C series features a polypropylene film construction with a capacitance of 33 nF and a tolerance of ±5 %. This capacitor is designed for high voltage applications with a rated DC voltage of 3 kV and AC voltage of 750 V, making it suitable for industrial electronics, power semiconductor circuits, snubber circuits, and motor applications.
This component uses a through hole mounting style with wire terminals and lead length of 6 mm. The capacitor’s compact size (33 mm length, 20.5 mm width, and 20.5 mm height) allows for versatile PCB layouts. It operates reliably in a wide temperature range from -40°C to 85°C, meeting industrial and power electronics standards such as EN 61071, IEC 61071, and VDE 0560.
The low equivalent series resistance (ESR) of 28 mΩ and a dissipation factor of 0.0005% enable efficient energy use and minimal heat generation in high-frequency applications.
Typical applications include voltage spike suppression, blocking, clamping, and decoupling in lighting ballasts, power supplies, and motor drives. The self-healing metallised polypropylene film construction enhances reliability and long service life under electrical stress.
Polypropylene film dielectric ensuring low loss and high ripple current handling. Rated for 3 kV DC and 750 V AC operation in demanding industrial circuits. Compact through hole design with 6 mm leads for easy PCB installation.
Operating temperature from -40°C up to +85°C suitable for harsh environments. Low ESR of 28 mΩ minimizes heat and maximizes efficiency. Compliant with international standards EN 61071, IEC 61071, and VDE 0560. Plastic case construction improves safety and durability.
Ideal for power semiconductor snubbers, motor controls, and electronic ballasts. Explore more Film Capacitors at EnvMart for diverse electrical component applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance rating of 33 nF with a tolerance of ±5 %.
It is rated for a DC voltage of 3 kV and an AC voltage of 750 V.
The operating temperature range is from -40°C to 85°C, making it suitable for industrial environments.
The equivalent series resistance (ESR) is 28 mΩ, which helps reduce heat generation and increase efficiency.
This model utilizes a through hole mounting style with wire terminals.
The dimensions are 33 mm in length, 20.5 mm in width, and 20.5 mm in height.
The lead length is 6 mm, which facilitates easy installation on PCBs.
It complies with international standards including EN 61071, IEC 61071, and VDE 0560.
The dissipation factor is 0.0005%, ensuring minimal power loss in circuits.
Typical applications include voltage spike suppression, blocking, clamping, and decoupling in power supplies and motor drives.
It features a polypropylene film dielectric, which provides low losses and high ripple current capability.
The capacitor is packaged in a plastic bag for safe transportation and storage.
