Molex KK 254 Series Right Angle Through Hole Pin Header 6 Contacts 2.54 mm Pitch 1 Row Unshrouded 22-28-8063
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 4A |
| Mount Type | Through Hole |
| Housing Material | High Temperature Thermoplastic |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Tin |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | CSA LR19980, UL E29179 |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.05mm |
| Mating Pin Length | 8.23mm |
Key Features
- Constructed with high temperature thermoplastic housing for durability.
- Supports current rating of 4A and voltage rating of 500V.
- Features gold plated brass male contacts ensuring excellent conductivity.
- Right angle orientation with single row design enhances PCB mounting flexibility.
- Termination type is tin ensuring reliable soldering.
- Tail pin length is 3.05 mm with mating pin length of 8.23 mm.
- Unshrouded design facilitates easy connection and inspection.
- Complies with CSA LR19980 and UL E29179 standards for quality assurance.
Product Description
Molex 22-28-8063 KK 254 Series Right Angle Through Hole Pin Header features a durable high temperature thermoplastic housing and brass male contacts plated in gold for superior electrical performance. Rated for 4A current and 500V voltage, this connector ensures reliable wire-to-board connections in demanding industrial and electronics environments.
The pin header has a 2.54 mm pitch across 6 contacts arranged in a single row with right angle orientation, providing flexible PCB mounting options. The termination type uses tin plating for effective through hole soldering. Tail and mating pin lengths measure 3.05 mm and 8.23 mm respectively, supporting robust mechanical and electrical contact.
This unshrouded connector complies with CSA LR19980 and UL E29179 standards, confirming its safety and quality. Produced in India, it is ideal for applications in electronics assembly, power connectors, and industrial equipment requiring secure wire-to-board interfaces.
High temperature thermoplastic housing guarantees mechanical and thermal stability. Gold plating on brass contacts enhances corrosion resistance and conductivity. Supports 4A current and withstands 500V voltage loads. Right angle, single row design fits compact PCB layouts.
Through hole mount provides strong solder joints for durability. Compliant with recognized industry standards for safety and reliability. Unshrouded for easy visual inspection and connection adjustments. Manufactured in India ensuring local quality compliance.
This Molex KK 254 pin header series is widely used in electronics manufacturing, industrial control systems, and power distribution assemblies. It facilitates dependable electrical connections and integration in a variety of industrial, commercial, and electronic equipment applications.
Explore more PCB Header and Connector solutions on EnvMart for high-quality products tailored for your manufacturing and prototyping needs.
Explore more products in our PCB Headers category.
