| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C6V8YL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 1μA |
| Nominal Zener Voltage Vz | 6.8V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 80Ω |
| Typical Voltage Temperature Coefficient | 1.2mV/K |
Nexperia BZX8850S-C6V8YL is a low-current voltage regulator Zener diode designed for regulated voltage applications in electronic circuits. Housed in an ultra-small DFN1006BD-2 plastic surface mount package with side-wettable flanks, it offers efficient space saving on PCB designs.
This Zener diode features a nominal Zener voltage of 6.8 V, with a tolerance of ±5%, and a maximum power dissipation of 365 mW. The device operates reliably within a temperature range from -55°C to +150°C, making it suitable for automotive and industrial applications, compliant with AEC-Q101.
The diode is specified at a low test current of 50 μA, making it ideal for low bias and portable battery-powered designs requiring voltage regulation and protection. Its maximum reverse leakage current is only 1 μA, and the typical voltage temperature coefficient is 1.2 mV/K, ensuring consistent voltage regulation under varying temperature conditions.
The physical package measures 1 mm in length and 0.47 mm in height, with two pins configured for single element use. This diode is commonly used in industrial, automotive, and electronic manufacturing applications for voltage stabilization, surge protection, and voltage reference tasks.
Surface mount DFN1006BD-2 package for compact PCB footprint. 365 mW maximum power dissipation suitable for low power circuits. Voltage tolerance of ±5% ensures accurate voltage regulation. Low test current of 50 μA optimizes performance in portable devices.
Wide operating temperature from −55°C to +150°C supports harsh environments. Automotive graded AEC-Q101 compliant for reliability. Typical voltage temperature coefficient of 1.2 mV/K maintains stability. Maximum reverse leakage current of 1 μA reduces power loss.
Used in voltage regulation, industrial electronics, automotive systems, and power management circuits. Discover a wide range of semiconductor components including Zener Diodes at EnvMart to support your design and manufacturing requirements.
