| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C6V2YL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 1μA |
| Nominal Zener Voltage Vz | 6.2V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 160Ω |
| Typical Voltage Temperature Coefficient | 0.4mV/K |
Nexperia BZX8850S-C6V2YL is a high-performance Zener diode designed as a single-element voltage regulator diode with a nominal voltage of 6.2 V. This device is housed in an ultra-small leadless surface mount DFN1006BD-2 package, which allows for efficient space utilization in modern electronic circuitry.
The diode has a maximum power dissipation rating of 365 mW, making it well suited for low-power regulation tasks in portable and battery-powered devices. Its very low test current of 50 μA enables efficient voltage regulation with minimal energy loss.
The diode boasts an operating temperature range from -55°C up to 150°C, ensuring stable operation under harsh environmental conditions. Compliance with the automotive standard AEC-Q101 highlights its robustness and suitability for automotive applications.
This device's low typical voltage temperature coefficient of 0.4 mV/K guarantees consistent performance across varying temperatures, which is critical for precision electronics and industrial applications.
The package dimensions are compact with a height of 0.47 mm and length of 1 mm, facilitating compact PCB designs. The 2-pin configuration allows for easy surface mounting and efficient circuit integration.
Single element Zener diode for voltage regulation. Nominal Zener voltage of 6.2 V ± 5% tolerance. 365 mW maximum power dissipation. Surface mount DFN1006BD-2 package with 2 pins. Test current of 50 μA ensuring low bias current operation.
Operating temperature range of -55°C to 150°C. Complies with AEC-Q101 automotive standard. Maximum Zener impedance of 160 Ω. Maximum reverse leakage current of 1 μA. Typical voltage temperature coefficient of 0.4 mV/K.
This Zener diode is ideal for industrial, automotive, and electronic applications requiring compact, reliable voltage regulation components. Its small footprint and compliance standards make it suitable for high-density PCB layouts and automotive electronics.
