Molex OneBlade Series Vertical Surface PCB Header, 4 Contacts, 1 mm Pitch, 2 Row, Shrouded 214094-0040

Molex 214094-0040 is a OneBlade Series vertical surface PCB header designed for wire-to-board connector applications. It features 4 male brass contacts with matt tin plating installed in a durable polyamide housing. This 2-row shrouded connector has a 1 mm pitch, offering a compact layout for PCB designs.

The connector supports reliable solder termination and is rated for 2.5A current and 100 Vrms voltage, ensuring robust electrical performance. It operates efficiently within a temperature range of -40°C to 105°C, making it suitable for harsh industrial, electronic manufacturing, and equipment applications.

Its shrouded design protects the contacts and supports up to 30 mating cycles for durable field use. The 2 mm mating pin length ensures stable and secure connections with compatible counterparts. Compliance with EU RoHS and China RoHS regulations verifies its environmental and safety standards.

This Molex PCB header is ideal for electronic components, power supplies, control systems, and PCB assembly in industrial, laboratory, and manufacturing environments. The compact size and robust build support high-density PCB layouts and reliable mechanical performance.

This PCB header features a vertical orientation suitable for wire-to-board connections. It has 4 brass contacts plated with matt tin to ensure efficient electrical conductivity. The housing is made of durable polyamide for enhanced mechanical strength and temperature resistance.

Designed for surface mounting with solder termination type, ensuring secure and reliable installation. Operates reliably in temperature ranges from -40°C to 105°C, suitable for a wide range of industrial environments. The connector supports a current rating of 2.5A and a voltage rating of 100 Vrms.

It is a shrouded type connector with a 1 mm pitch and 2 row configuration for compact PCB designs. The mating pin length is 2 mm, allowing easy and stable connections. The product is compliant with EU RoHS and China RoHS standards, ensuring environmental safety.

Country of origin is Korea, Republic Of, reflecting international manufacturing standards.
