Abracon Shielded Surface Mount Inductor with Nickel Zinc Ferrite Core 220 μH ±30/±20 %, 800 mA Idc ASPI-8040S-221M-T

Abracon ASPI-8040S-221M-T is a shielded surface mount inductor designed with a nickel zinc ferrite core providing an inductance of 220 μH with tolerances of ±30/±20 %. This wirewound component supports a maximum DC current rating of 800 mA and exhibits a very low DC resistance of 0.008 ohms.

The component is constructed for surface mount technology (SMT) and packaged in tape and reel format, facilitating efficient automated PCB assembly. Measuring 8 mm in length and 4.2 mm in both height and depth, it is suitable for designs requiring a compact footprint.

Operating temperatures span from -40°C to 125°C, making the inductor robust for use in a wide temperature range including industrial and commercial electronics.

The magnetic shielding significantly reduces electromagnetic interference, enhancing signal integrity in complex electronic circuits. The 4-pin termination style ensures reliable soldering and mechanical stability on PCBs.

Typical applications include portable communication devices, office automation equipment, LCDs, DVDs, modems, set-top boxes, and DC/DC converters in power management circuits.

The core is made of premium nickel zinc ferrite ensuring stable inductance characteristics and performance consistency over time and temperature variations. The induction tolerance and energy storage capacity suit a variety of power electronics applications.

The inductor features a magnetically shielded wirewound construction to reduce electromagnetic interference. Designed for surface mount applications with tape and reel packaging for automated assembly. Includes a low DC resistance of 0.008 Ω enabling efficient power handling.

Operating temperature range from -40°C to 125°C ensures stability in harsh environments. The compact package measures 8 mm in length and 4.2 mm in height and depth for space-constrained designs. Ideal for use in portable communication equipment, DC/DC converters, set-top boxes, and consumer electronic devices.

Core material is high-quality nickel zinc ferrite for reliable inductance performance. Termination style is surface mount soldered to PCB pads with a 4-pin configuration.
