Panasonic ETQP5M Shielded Wirewound Surface Mount Inductor Metal Composite Core 1μH ±20 % 27.5A Idc ETQP5M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 10.9mm |
| Model | ETQP5M |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | ETQP5M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 1μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 27.5A |
| Pin Count | 2 |
| Maximum DC Resistance | 2.53mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- The inductor is constructed with a wirewound design providing high reliability and stability.
- It includes shielding to reduce electromagnetic interference and noise.
- The component is housed in a surface mount package measuring 10.9 mm in length, 5 mm in height, and 10 mm in depth.
- Designed for operating temperatures from -40°C to 150°C, meeting automotive AEC-Q200 standards.
- Offers low maximum DC resistance of 2.53 mΩ ensuring efficient current handling.
- Suitable for high bias current applications with noise filtering capabilities.
- Packaging is provided as a tape and reel format, ideal for automated assembly.
- Maximum self-resonant frequency of 100 kHz enhances performance in various circuit environments.
Product Description
Panasonic ETQP5M Shielded Wirewound Surface Mount Inductor with a metal composite core offers 1μH inductance with ±20 % tolerance and a maximum DC current of 27.5 A. The device is engineered for high heat resistance and reliability, utilizing a wirewound construction and metal composite core material that contributes to inductance stability using ferrous alloy magnetic material.
The inductor is shielded to minimize electromagnetic interference and noise, making it suitable for applications requiring high temperature operation up to 150°C, including self-heating scenarios. It meets the automotive AEC-Q200 standard, ensuring robust performance in automotive and industrial environments.
Dimensions for this surface mount component are 10.9 mm in length, 5 mm in height, and 10 mm in depth, with surface mount termination style for efficient PCB integration. The maximum DC resistance is low at 2.53 mΩ, supporting high current applications of up to 27.5 A.
This inductor is moulded and designed with a shielded construction to reduce audible noise and improve noise filtering for various drive circuitry. It has a maximum self-resonant frequency of 100 kHz, enhancing its effectiveness in power management and filtering circuits.
The inductor construction uses wirewound technology for superior performance. The product is packaged in tape and reel format for assembly line use. High bias current and temperature stability offer reliable operation for demanding industrial, automotive, and electronic component applications.
Shielding improves noise immunity in sensitive electronic circuits. Meets RoHS compliance and is suitable for various power and passive component needs in electronics manufacturing.
This Panasonic ETQP5M Surface Mount Inductor is ideal for use in power electronics, automotive systems, communication devices, and industrial controls where efficient, reliable inductors are required.
Explore more surface mount Inductors and passive electronic components in the Electronics Components category on EnvMart for comprehensive industrial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ETQP5M inductor has an inductance value of 1μH with a tolerance of ±20%.
This model supports a maximum DC current of 27.5A.
The dimensions of the ETQP5M are 10.9 mm in length, 5 mm in height, and 10 mm in depth.
The maximum operating temperature for this inductor is 150°C.
It features a wirewound construction which provides high reliability and stability.
The inductor is packaged in a tape and reel format, making it suitable for automated assembly.
The maximum DC resistance is 2.53 mΩ, allowing for efficient current handling.
Yes, it meets the automotive AEC-Q200 standard and is RoHS compliant.
The maximum self-resonant frequency of this inductor is 100 kHz.
The core material of the ETQP5M is a metal composite, which contributes to its inductance stability.
This inductor features a surface mount termination style for efficient PCB integration.
It can operate in a temperature range from -40°C to 150°C.
