Panasonic WE-GF 1210 Unshielded Wirewound Surface Mount Inductor 33 μH ±10% 70mA 744764133
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 2.2mm |
| Length | 3.2mm |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | WE-GF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 33μH |
| Standards/Approvals | RoHS, REACH |
| Package/Case | 1210 |
| Maximum DC Current | 70mA |
| Pin Count | 2 |
| Maximum DC Resistance | 5.6Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 17MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- Compact 1210 package size suitable for surface mounting.
- Capable of operating in temperatures from -40°C to 105°C.
- Featuring a maximum DC resistance of 5.6 Ω ensuring efficient performance.
- Ferrite core construction enhances inductive properties.
- Maximum self-resonant frequency of 17 MHz optimizes signal integrity.
- Wirewound inductor construction ensures precise inductance and quality factor.
- Compliance with RoHS and REACH environmental standards.
- Minimum quality factor of 30 supporting high frequency circuits.
Product Description
Wurth Elektronik 744764133 (WE-GF series) is a high-quality unshielded wirewound surface mount inductor featuring a ferrite core and an inductance value of 33 μH with ±10% tolerance. It is designed to handle a maximum DC current of 70 mA, making it suitable for demanding high frequency applications such as HF amplifiers, oscillators, transponders, LC filter circuits, and adapter networks.
The inductor comes in a compact 1210 package (3.2mm length, 2.5mm depth, 2.2mm height), without shielding, and supports operating temperature ranges from -40°C to 105°C. The device has a maximum DC resistance of 5.6 ohms and a maximum self-resonant frequency of 17 MHz, ensuring optimal performance in HF circuits. Its wirewound construction combined with a ferrite core provides excellent inductive properties and a minimum quality factor of 30.
This inductor is packaged using tape and reel methods to enable efficient automated PCB assembly methods. It complies with RoHS and REACH environmental standards, demonstrating its suitability for modern sustainable electronics manufacturing.
Compact 1210 package size supports automated SMT assembly. Wide operating temperature range of -40°C to 105°C ensures reliability. Low DC resistance of 5.6 Ω reduces power losses. Ferrite core material provides high inductance stability.
High-frequency capability with self-resonant frequency up to 17 MHz. Wirewound construction for precise inductance and quality factor. Compliant with RoHS and REACH directives for environmental safety. Tape & Reel packaging optimizes production processes.
These inductors are widely used in industrial, telecommunications, communications equipment, and electronic circuit applications requiring precise inductance at high frequencies. They are ideal for HF amplifiers, oscillator circuits, and filter components.
Explore more electronic passive components like Inductors and connectors at EnvMart, your destination for industrial-grade electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductor has an inductance value of 33 μH with a tolerance of ±10%.
It can handle a maximum DC current of 70 mA, making it suitable for various high-frequency applications.
The dimensions of the 1210 package are 3.2 mm in length, 2.5 mm in depth, and 2.2 mm in height.
The maximum self-resonant frequency is 17 MHz, which optimizes signal integrity in high-frequency circuits.
It operates within a temperature range of -40°C to 105°C, ensuring reliability in various environments.
The maximum DC resistance is 5.6 Ω, which helps in reducing power losses during operation.
It features a wirewound construction, which ensures precise inductance and a high quality factor.
It complies with RoHS and REACH environmental standards, demonstrating its suitability for sustainable electronics manufacturing.
It is packaged using tape and reel methods, which enables efficient automated PCB assembly.
This inductor is suitable for high-frequency applications such as HF amplifiers, oscillators, and LC filter circuits.
The minimum quality factor is 30, which supports high-frequency circuit performance.
The core material is ferrite, which enhances the inductive properties of the inductor.
