Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket 8-Contact 2 Row 2.54 mm Pitch 500V 3A 613008216921

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket 8-Contact 2 Row 2.54 mm Pitch 500V 3A 613008216921

Name: Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket 8-Contact 2 Row 2.54 mm Pitch 500V 3A 613008216921
Brand: Wurth Elektronik
SKU: 173116
Price: 2.14 USD
Availability: InStock



Category PCB Socket Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	500V
Brand	Wurth Elektronik
Orientation	Bottom Entry
Current	3A
Mount Type	Through Hole
Contact Material	Copper Alloy
Series	WR-PHD
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	PCB Socket
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	8
Connector System	Board-to-Board

Key Features

This socket supports a maximum current of 3A.
Features a robust copper alloy contact material with gold plating for reliable connectivity.
Operates at voltages up to 500V AC.
Designed with a bottom entry orientation and through-hole mount type for PCB integration.
Suitable for operating temperatures from -40°C up to 105°C.
The product complies with RoHS standards ensuring environmental safety.
Supports up to 25 mating cycles providing durability.
Originates from Taiwan, Province Of China.

Product Description

Wurth Elektronik 613008216921 is a bottom entry through hole PCB socket designed with 8 contacts arranged in 2 rows with a 2.54 mm pitch for secure board-to-board connections. It features a copper alloy contact material with gold plating, offering excellent conductivity and corrosion resistance. The socket supports a current rating of 3A and withstands voltages up to 500V AC, making it reliable for various electronic applications.

Operating temperature ranges from -40°C to +105°C, ensuring performance under diverse environmental conditions. The socket is built for durability with a rated 25 mating cycles, suitable for repeated insertion and removal scenarios in industrial, electronic manufacturing, and laboratory setups.

This PCB socket is RoHS compliant, supporting green manufacturing initiatives. It is designed for through-hole mounting with a bottom entry orientation, facilitating easy integration on printed circuit boards. The product is ideal for use in electronic components, power connectors, and board-to-board connection systems requiring high reliability and consistent electrical performance.

Supports up to 3A current for moderate power applications. Gold-plated copper alloy contacts ensure long-term electrical integrity. High voltage rating up to 500V AC for safety and performance. Compatible with 2.54 mm pitch electronic boards and connectors.

Compliant with RoHS for environmentally safe usage. Designed for through-hole mounting and bottom entry orientation. Durable with 25 mating cycles rating. Manufactured in Taiwan, Province Of China.

This Wurth Elektronik WR-PHD Series PCB socket is well suited for use in industrial electronics assembly, manufacturing, electronic testing, communication equipment, and other electronic component applications. It ensures secure and reliable connections for PCB designs requiring robust bottom-entry sockets.
