Weidmüller LSF Series PCB Terminal Block 6-Contact 5.08 mm Pitch 1 Row 500V 17.5A 1826100000

Weidmüller 1826100000 LSF Series PCB Terminal Block is a high-quality electrical component intended for industrial and electronic applications requiring reliable and fast PCB connections. This 6-contact single row terminal block features a 5.08 mm pitch, enabling compact, multi-layered PCB designs.

Manufactured with a durable fibreglass liquid crystal polymer housing, it withstands demanding operating conditions. The push-in wire connection system allows secure and tool-free conductor insertion, supporting wire sizes from 0.13 to 1.5 mm² (28 AWG to 14 AWG), suitable for currents up to 17.5A and voltages up to 500V.

The terminal block is engineered for fully automatic assembly using standard SMT reflow soldering processes, ensuring high consistency and productivity in manufacturing environments. Potentials and clamping points are clearly marked with colored push buttons to aid installation and servicing.

Standards compliance with IEC 61984 and IEC 60664-1 guarantees safety and quality for industrial, electronic, and commercial applications. Its compact form factor, 29.6 mm width and 7.8 mm depth, facilitates space-saving PCB layouts.

Applications include electronic circuit manufacturing, power distribution, control panels, and automated industrial systems where compact and reliable PCB terminal connections are essential.

Push-in conductor connection enables tool-free wiring. Supports automated SMT assembly with reflow soldering compatibility. Compact and robust fibreglass liquid crystal polymer housing. Clear marking system for potentials and clamping points.

Complies with relevant IEC standards for safety. Suitable for a wide range of wire sizes and current ratings. Ideal for industrial, electronic, commercial, and manufacturing use. Explore related PCB Terminal Blocks and connectors in our Electronics Components category for expanded system design options.
