Weidmüller LSF Series PCB Terminal Block 5-Contact 7.5 mm Pitch 1 Row Push-In 800V 17.5A 1473970000
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 800V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | 90° |
| Current | 17.5A |
| Depth | 14.75mm |
| Width | 34.2mm |
| Housing Material | Fibreglass Liquid Crystal Polymer |
| Series | LSF |
| Number of Rows | 1 |
| Pitch | 7.5mm |
| Standards/Approvals | CSA, IEC, RoHS, UL |
| Number of Contacts | 5 |
| Minimum Wire Size mm² | 2mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Push-in |
Key Features
- Features a push-in wire connection method for easy and reliable installation.
- Constructed with fibreglass liquid crystal polymer housing for high durability.
- Supports current up to 17.5A and voltage rating of 800V.
- Compatible with wire sizes from 2mm² (min) to 1.5mm² (max).
- Designed with a 7.5 mm pitch and 90° orientation for PCB mounting.
- Single-row terminal block with black housing color.
- Meets CSA, IEC, RoHS, and UL standards for safety and compliance.
- Optimised for automatic assembly and reflow soldering processes.
Product Description
Weidmüller 1473970000 LSF Series PCB Terminal Block is designed to provide reliable and efficient electrical connection for printed circuit boards. This terminal block features 5 contacts arranged in a single row with a 7.5 mm pitch, making it suitable for compact and space-saving PCB layouts. The push-in wire connection technology allows for effortless conductor insertion and removal without the need for tools, ensuring fast assembly and maintenance.
The housing of this terminal block is made from fibreglass liquid crystal polymer which offers excellent mechanical strength, thermal stability, and resistance to various environmental factors. It supports wire sizes ranging from 2 mm² minimum to 1.5 mm² maximum, compatible with both solid wires and ferrules. Rated for a current of 17.5A and a voltage of 800V, this terminal block is suitable for a wide range of industrial and commercial electronic applications.
The 90° orientation and black color housing provide flexible installation options in different types of control panels and electronic assemblies. The product complies with major international standards including CSA, IEC, RoHS, and UL, ensuring safety and sustainability in its use.
Push-in wire connection method provides quick and secure wiring. Fibreglass liquid crystal polymer housing ensures durability and thermal resistance. 5 contacts with a 7.5 mm pitch for compact PCB layouts. Supports wire sizes from 2mm² to 1.5mm², suitable for solid and ferruled wires.
Rated for 17.5A current and 800V voltage for versatile industrial use. Complies with CSA, IEC, RoHS, and UL standards. Designed for fully automated assembly processes, including reflow soldering.
This Weidmüller PCB terminal block is ideal for electronic manufacturing, industrial control systems, automation equipment, and power distribution units. Its design supports efficient production workflows and reliable electrical connections that meet stringent industry requirements.
Explore the full range of electronics components and simplify your PCB wiring solutions with Weidmüller products at EnvMart.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for a voltage of 800V and a current of 17.5A.
It supports wire sizes ranging from a minimum of 2 mm² to a maximum of 1.5 mm², and is compatible with both solid wires and ferrules.
The contacts are arranged with a pitch of 7.5 mm and a 90° orientation, suitable for PCB mounting.
The housing is constructed from fibreglass liquid crystal polymer, which provides high durability and thermal stability.
This model features 5 contacts arranged in a single row.
It complies with CSA, IEC, RoHS, and UL standards, ensuring safety and compliance for various applications.
The dimensions of this terminal block are 14.75 mm in depth and 34.2 mm in width.
It utilizes a push-in wire connection method, allowing for easy and reliable installation without the need for tools.
Yes, it is designed to be optimized for automatic assembly and reflow soldering processes.
It is ideal for electronic manufacturing, industrial control systems, automation equipment, and power distribution units.
The terminal block is manufactured in India.
The housing of this terminal block is black in color.
