Honeywell Piezoresistive Pressure Sensor Through Hole 8 Pin SIP HSCSANN015PA2A3

Free Delivery in India | Lowest Global Shipping Charges

Honeywell Piezoresistive Pressure Sensor Through Hole 8 Pin SIP HSCSANN015PA2A3

Name: Honeywell Piezoresistive Pressure Sensor Through Hole 8 Pin SIP HSCSANN015PA2A3
Brand: Honeywell
SKU: 172066
Price: 62.58 USD
Availability: InStock



Category Pressure Sensor ICs Brand Honeywell Condition New

Specifications

Country of Origin	India
Accuracy	±0.25 %
Brand	Honeywell
Maximum Operating Pressure	103 kPa
Height	13.75mm
Length	10mm
Model	HSCSANN015PA2A3
Sensor Type	Piezoresistive Pressure Sensor
Width	13.3mm
Mount Type	Through Hole
Series	HSC
Maximum Operating Temperature	85°C
Port Type	Single Axial Barbed
Package Type	SIP
Minimum Operating Temperature	-20°C
Maximum Output Voltage	6V
Pin Count	8
Maximum Supply Voltage	5V
Minimum Supply Voltage	3.3V
Minimum Output Voltage	-0.30V
Minimum Operating Pressure	0psi
Maximum Overload Pressure	206kPa

Key Features

Maximum operating pressure of 103 kPa ensures reliable measurement in low-pressure applications.
Provides ratiometric analog or digital output for flexible integration.
Highly accurate with a precision of ±0.25% across its full range.
Operates from a single supply voltage of 3.3 V to 5 V.
Designed for temperatures from -20°C to 85°C for versatile usage.
Compact dimensions of 13.75mm height, 13.3mm width and 10mm length suit space-limited designs.
Features built-in calibration and temperature compensation for sensor offset and sensitivity.
Maximum overload pressure up to 206 kPa for durable operation above rated pressures.

Product Description

Honeywell Technologies HSCSANN015PA2A3 is a piezoresistive pressure sensor designed in an 8-pin SIP through hole package for precise low-pressure sensing. It supports ratiometric analog and digital outputs to accommodate a wide range of sensing systems.

The sensor operates reliably with a maximum operating pressure of 103 kPa and withstands overload up to 206 kPa. Accuracy is maintained at ±0.25% through an onboard application specific integrated circuit (ASIC) that provides full calibration and temperature compensation, ensuring consistent sensor offset, sensitivity, and non-linearity performance across the operating temperature range from -20°C to 85°C.

Power supply flexibility from 3.3 V to 5 V makes it compatible with standard electronic circuitry. The device's compact physical dimensions (13.75mm height, 13.3mm width, 10mm length) and single axial barbed port facilitate easy integration in space-constrained industrial and laboratory environments.

This sensor is ideally suited for applications requiring precise pressure monitoring such as industrial process control, HVAC systems, automotive sensing, and water treatment monitoring. The device promotes system reliability by detecting internal failures including burst sensors and extends battery life in portable equipment.

Maximum operating pressure of 103 kPa. Maximum overload pressure of 206 kPa. Accuracy of ±0.25%. Operating temperature range from -20°C to 85°C. Supply voltage range of 3.3 V to 5 V. Single axial barbed port type for easy interfacing.

Compact 8-pin SIP through hole package. Onboard ASIC for full calibration and temperature compensation. Durable design suitable for industrial and automotive applications.

Set includes 1 Pc Honeywell HSCSANN015PA2A3 piezoresistive pressure sensor with 8-pin SIP through hole mounting. Explore more precision pressure sensors and sensor ICs in EnvMart's Electronics & Electricals catalog for industrial-grade sensing solutions.
