Molex C-Grid III Series Straight Through Hole Pin Header, 12 Contact, 2.54 mm Pitch, 2 Row, Unshrouded, Brass 90131-0766
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Suitable for both board to board and wire to board applications.
- Features a breakaway design for added design flexibility.
- High retention force pins ensure secure mating connection.
- Contacts provide strong mechanical stability after soldering.
- Polyester housing with brass contacts plated in gold.
- Designed for operating voltages up to 350V and currents up to 3A.
- Operates reliably within a temperature range from -55°C to 125°C.
- Male contact gender with tail pin length of 2.9 mm and mating pin length of 6.75 mm.
Product Description
Molex 90131-0766 C-Grid III Series Straight Through Hole Pin Header is a precision-engineered electronic component designed for reliable electrical connections in a variety of industrial and commercial applications. Featuring 12 contacts arranged in 2 rows with a 2.54 mm pitch, this unshrouded pin header is intended for through hole mounting on printed circuit boards (PCBs).
The pin header uses a polyester housing which ensures durability and electrical insulation. Its brass contacts are plated with gold, providing excellent conductivity and corrosion resistance. The pins have a breakaway design allowing customizable lengths for flexible circuit designs.
Electrical specifications include a current rating of 3A and operating voltage up to 350V. It functions reliably across a wide temperature range from -55°C to 125°C, suitable for harsh environmental conditions. The male contacts include a tail pin length of 2.9 mm for secure soldering and a mating pin length of 6.75 mm ensuring a firm connection with compatible sockets.
This Molex C-Grid III Series header meets international standards DIN 41651 and HE13/14, ensuring compatibility and quality manufacturing standards. Its secure high retention force and mechanical stability after soldering make it ideal for robust applications.
Common uses include industrial machinery controls, computer servers and monitors, medical devices, telecommunications equipment, white goods, automotive safety systems, and industrial electronic assemblies.
Suitable for board to board and wire to board connections. Breakaway design supports customizable PCB layouts. High retention pins ensure firm and reliable connections. Gold-plated brass contacts resist corrosion and maintain conductivity.
Wide temperature rating allows usage in demanding environments. Industry standard compliance guarantees broad compatibility.
For detailed design and integration, 3D models and technical documentation are available. This product provides a dependable solution for professional electronic assembly and manufacturing needs.
Explore similar Molex C-Grid III connectors and related PCB components in the Electronics & Electricals category on EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header has a current rating of 3A, making it suitable for various applications requiring reliable electrical connections.
It is designed to operate at a maximum voltage of 350V, ensuring compatibility with high-voltage applications.
The contacts are arranged with a pitch of 2.54 mm, which is a standard size for many PCB applications.
The housing is made of polyester, while the contacts are brass plated with gold for enhanced conductivity and corrosion resistance.
This model operates reliably within a temperature range of -55°C to 125°C, suitable for harsh environmental conditions.
It features 12 contacts arranged in 2 rows, allowing for versatile connections in electronic assemblies.
It is designed for through-hole mounting on printed circuit boards (PCBs), facilitating secure installation.
The tail pin length is 2.9 mm, which aids in secure soldering to the PCB.
The mating pin length is 6.75 mm, ensuring a firm connection with compatible sockets.
The contacts are male, designed for reliable mating with female sockets in various applications.
The breakaway design allows for customizable lengths of the pin header, providing flexibility in circuit design.
It meets international standards DIN 41651 and HE13/14, ensuring compatibility and quality manufacturing standards.
