Molex C-Grid III Series Pin Header, Straight Through Hole, 20 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0780

Molex 90120-0780 C-Grid III Series Straight Through Hole Pin Header is a high-quality connector designed for printed circuit board (PCB) interconnection requiring 20 contacts arranged in a single row with a 2.54 mm pitch. This unshrouded pin header provides reliable wire-to-board connectivity with robust brass contacts plated with gold for enhanced conductivity and corrosion resistance. The pins and housing are specifically engineered to withstand industrial operating conditions with a temperature range from -55°C to 125°C and a voltage rating of 350V.

The header features a breakaway design facilitating modular customization by allowing individual pins to be cut for tailored lengths to suit diverse PCB layouts. The solder termination type ensures a secure and permanent connection on the board, while the male contact gender supports standard mating with compatible sockets and housings within the C-Grid III interconnection family.

This pin header excels in maintaining high mechanical stability once soldered, and strong retention force ensures secure mating connections preventing disconnections from vibration or mechanical stress. Its polyester housing construction provides excellent electrical insulation and durability to satisfy rigorous industrial, telecommunication, computing, medical device, automotive safety electronics, and consumer product applications.

Single-row pin header with 20 male pins and 2.54 mm pitch. Brass contact material with gold plating for superior conductivity and corrosion resistance. Straight orientation and through-hole mount for stable PCB installation.

Operating temperature from -55°C to 125°C supports harsh environmental conditions. Current rating of 3A and voltage rating of 350V. Breakaway pins allow custom length configurations to fit design requirements. Housing material is polyester, ensuring robust insulation and mechanical strength.

Solder termination for reliable PCB connection. Designed for industrial, computer, medical, telecom, transportation, and consumer electronics.

This C-Grid III series pin header is part of Molex’s extensive range of PCB connectors that meet contemporary interconnection standards and design flexibility demands. Suitable for both wire-to-board and board-to-board technologies, it is a dependable solution in electronics manufacturing and assembly. Browse more Molex products and PCB connectors in the Electronics Components category at EnvMart for optimized PCB assembly solutions.
