TDK 6045 Shielded Wirewound Surface Mount Inductor with Ferrite Core 330 μH ±0.2 % 500 mA IDC VLS6045EX-331M
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 6mm |
| Model | VLS6045EX-331M |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 330μH |
| Standards/Approvals | RoHS |
| Package/Case | 6045 |
| Maximum DC Current | 500mA |
| Maximum DC Resistance | 1.872Ω |
| Inductance Tolerance | ±0.2 % |
| Termination Style | Surface Mount |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Ferrite core construction ensures high magnetic shield performance.
- Compact 6045 package size with dimensions 6 mm x 6 mm x 4.5 mm.
- Maximum DC resistance of 1.872 Ω supports efficient current flow.
- Automotive standard AEC-Q200 certified for reliable operation.
- Operating temperature range from -40°C to 105°C for diverse applications.
- Surface mount termination style for high-density PCB mounting.
- Magnetic shield reduces electromagnetic interference in power circuits.
- Packaging supplied on tape and reel for automated assembly.
Product Description
TDK VLS6045EX-331M is a shielded wirewound surface mount inductor designed with a ferrite core, offering an inductance of 330 μH with a tight tolerance of ±0.2%. It supports a maximum DC current of 500 mA, making it suitable for demanding power circuit applications.
This inductor adopts a robust magnetic shield construction using ferrite material to minimize electromagnetic interference, ensuring signal integrity and circuit stability in compact electronic designs. The 6045 package size (6 mm length, 6 mm depth, and 4.5 mm height) facilitates high-density mounting on printed circuit boards with surface mount termination style.
Certified to automotive standard AEC-Q200, the VLS6045EX-331M operates reliably across a wide temperature range from -40°C to 105°C, suitable for automotive, industrial, and commercial electronics.
The maximum DC resistance is 1.872 Ω, optimized for efficient power handling while maintaining compact size and shielding.
Supplied on tape and reel packaging, this inductor supports automated pick-and-place assembly processes. The ferrite core and shielded wire wound construction enable enhanced current capacity and electromagnetic compatibility in power converters, power supplies, and filtering applications.
Ferrite core construction for magnetic shielding performance. Compact 6045 package size for high-density mounting. 500 mA maximum DC current rating ensures robust power handling. ±0.2% inductance tolerance for precision electronic design.
Operating temperature range from -40°C to 105°C for harsh environments. Surface mount termination style compatible with modern PCB assembly. Meets automotive standard AEC-Q200 for quality assurance. RoHS compliant and environmentally friendly.
This product is ideal for use in industrial, automotive, telecommunications, and consumer electronics requiring reliable inductors with low electromagnetic interference and stable performance. Browse the Electronics Components category at EnvMart for similar Surface Mount Inductors and passive components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this surface mount inductor is 330 μH with a tolerance of ±0.2%.
This model supports a maximum DC current of 500 mA.
The dimensions of the 6045 package size are 6 mm in length, 6 mm in depth, and 4.5 mm in height.
The operating temperature range for this inductor is from -40°C to 105°C.
It uses a surface mount termination style, suitable for high-density PCB mounting.
The maximum DC resistance of this inductor is 1.872 Ω.
Yes, it is certified to the automotive standard AEC-Q200, ensuring reliable operation in automotive applications.
The core of this inductor is made from ferrite, which enhances its magnetic shielding performance.
It is supplied on tape and reel packaging, which supports automated assembly processes.
This model is RoHS compliant, indicating it meets environmental standards for hazardous substances.
This inductor is suitable for use in industrial, automotive, telecommunications, and consumer electronics applications requiring low electromagnetic interference and stable performance.
