Samtec Right Angle Surface Pin Header 14 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-107-01-L-DH-A-P-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Right Angle |
| Model | TSM-107-01-L-DH-A-P-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold or Tin |
| Number of Contacts | 14 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- Features a 2-row configuration with unshrouded design for flexible assembly.
- Constructed with a black liquid crystal polymer housing for durability.
- Phosphor bronze contacts plated with 0.25 μm gold on posts and matte tin on tails for reliable conductivity.
- Operates efficiently in temperatures ranging from -55°C to 125°C.
- Rated for a maximum voltage of 475 VAC ensuring safe electrical performance.
- Surface mount technology (SMT) for precise board integration.
- Male contact gender suitable for various PCB connection requirements.
- Right angle orientation optimizes PCB design layouts.
Product Description
The Samtec TSM-107-01-L-DH-A-P-TR is a high-quality right angle surface mount pin header designed for reliable board-to-board electrical connections. It features 14 phosphor bronze contacts arranged in 2 rows with a 2.54 mm pitch, housed within a robust liquid crystal polymer insulator. This unshrouded header facilitates efficient circuit interconnection in various industrial and commercial electronic applications.
Constructed for durability and optimal performance, the contacts are plated with 0.25 micrometers of gold on the mating posts and matte tin on the tail ends, enhancing conductivity and corrosion resistance. The component supports operating temperatures from -55°C up to 125°C, making it suitable for challenging environmental conditions. With a voltage rating of 475 VAC, it ensures safe operation within most board designs.
The right angle orientation and surface mount technology allow for compact and efficient PCB layouts, particularly beneficial in dense electronic assemblies used in industrial, laboratory, and manufacturing sectors. The male contact configuration and solder termination provide secure and versatile board installation.
The unshrouded design allows easy access and flexibility in connector mating, which is advantageous for customized electronic projects or standard production lines. 14 contacts arranged in 2 rows with 2.54 mm pitch. Black liquid crystal polymer housing ensures mechanical strength.
Phosphor bronze material with gold and tin plating increases contact reliability. Operating temperature range from -55°C to 125°C. Voltage rating of 475 VAC for electrical safety. Right angle orientation ideal for PCB space optimization.
Surface mount type for precise PCB integration. Male contact gender and solder termination for solid connectivity.
This header is ideal for use in electronic equipment manufacturing, power connectors, and other applications requiring reliable board interconnections. It combines robust construction with precise specifications to meet high-performance industrial standards.
Explore more PCB Header products and connectors by Samtec and other leading brands at EnvMart to find components best suited to your technical needs.
