Samtec SSW Series Straight Through Hole PCB Socket 15-Contact 1 Row 2.54 mm Pitch Solder SSW-115-01-F-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.7A |
| Model | SSW-115-01-F-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Constructed with liquid crystal polymer housing for durability.
- Phosphor bronze female contacts with gold plating for reliable conductivity.
- Current rating of 4.7 A per contact supports high performance.
- Operating temperature range from -55°C to 125°C suitable for varied environments.
- Standard and low insertion force contacts for easy assembly.
- Straight orientation ensures compatibility in standard PCB layouts.
- Designed for through-hole mounting providing solid mechanical attachment.
- Ideal for industrial and electronic applications requiring secure board-to-board connectors.
Product Description
Samtec SSW-115-01-F-S is a high-quality PCB socket designed for straight through-hole mounting with 15 contacts arranged in a single row spaced at 2.54 mm pitch. Manufactured from durable liquid crystal polymer housing and phosphor bronze contacts plated with gold, this socket offers excellent electrical performance and reliability.
Each contact supports a current rating of 4.7 A and the connector sustains voltage up to 655 V, making it suitable for a wide range of industrial, electronic, and manufacturing applications. The operating temperature range from -55°C to 125°C ensures stable performance in harsh environments.
The socket features standard and low insertion force contacts for ease of solder tail assembly onto printed circuit boards. Its straight orientation and through-hole mount type guarantee flexible design options for board-to-board connections.
The product complies with RoHS requirements, aligning with environmental regulations. This component is well-suited for use in electronic manufacturing, industrial equipment, and related applications where secure, reliable PCB connections are necessary.
Constructed with liquid crystal polymer housing for durability. Phosphor bronze contacts with gold plating ensure reliable conductivity. 15 contacts provide efficient board-to-board connection. Rated for 4.7 A current per contact suitable for high power needs.
Voltage rating of 655 V for robust electrical performance. Wide operating temperature from -55°C to 125°C for diverse applications. Straight orientation and through-hole mounting for compatibility. Standard and low insertion force contacts simplify assembly.
RoHS compliant supporting environmental safety standards. Ideal in electronic components, industrial tools, and manufacturing sectors. Explore more PCB Sockets and related components at EnvMart, your trusted source for industrial and electronic hardware.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
Each contact of the Samtec SSW-115-01-F-S PCB socket supports a current rating of 4.7 A, making it suitable for high power needs.
The voltage rating for this PCB socket is 655 V, ensuring robust electrical performance in various applications.
This model operates within a temperature range of -55°C to 125°C, allowing it to perform reliably in diverse environments.
The housing is made from liquid crystal polymer, while the contacts are phosphor bronze with gold plating for reliable conductivity.
This PCB socket features 15 contacts arranged in a single row, spaced at a 2.54 mm pitch.
The Samtec SSW-115-01-F-S is designed for through-hole mounting, providing a solid mechanical attachment to printed circuit boards.
This model has a straight orientation, ensuring compatibility with standard PCB layouts.
The termination type for this PCB socket is solder, which is suitable for secure connections on printed circuit boards.
Yes, this PCB socket complies with RoHS requirements, aligning with environmental regulations.
The connector system for the Samtec SSW-115-01-F-S is designed for board-to-board connections, facilitating efficient electrical pathways.
The contacts feature both standard and low insertion force designs, simplifying the assembly process onto printed circuit boards.
This PCB socket is manufactured in India, ensuring compliance with regional manufacturing standards.
