Samtec SSW Series Straight Through Hole PCB Socket 16-Contact 2 Row 2.54 mm Pitch Solder SSW-108-01-T-D

Samtec SSW-108-01-T-D is a high-quality Straight Through Hole PCB Socket designed for electronic applications requiring reliable board-to-board connections. This model features 16 female contacts arranged in 2 rows with a standard 2.54 mm pitch spacing, suitable for use in industrial, laboratory, manufacturing, and commercial electronic assemblies.

The socket’s housing is made from liquid crystal polymer, providing exceptional thermal stability and mechanical strength. It is engineered for through-hole mounting with solder termination, ensuring firm connectivity and long service life. The contact system employs patented Tiger Buy™ technology offering both standard and low insertion force contact options for versatile application.

Designed to operate at currents up to 6.3 A and voltages up to 655 V, this PCB socket also withstands operating temperatures ranging from -55°C to 105°C, making it suitable for harsh environmental conditions. Contacts are constructed from bronze and plated with tin to enhance conductivity and minimize corrosion, which ensures reliability over extended use.

The 2-row configuration with 2.5 mm row pitch supports compact and efficient circuit designs. The straight orientation facilitates easy integration into printed circuit boards. Manufactured in the United States, the Samtec SSW series PCB sockets are recognized for their quality and adherence to electronic component standards.

Features 16 female contacts arranged in 2 rows for board-to-board connectivity. Constructed from liquid crystal polymer housing ensuring durability. Supports through-hole mounting with solder termination type. Rated for a current of 6.3 A and voltage up to 655 V.

Contact material is bronze with tin plating for corrosion resistance. Operates reliably in temperature ranges from -55°C to 105°C. Includes Tiger Buy™ contact system for standard and low insertion force options. Row pitch is 2.5 mm with a 2.54 mm pitch between contacts.

Manufactured in the United States ensuring quality standards.

This PCB socket is ideal for use in industrial electronics, telecommunications equipment, computer and data processing devices, and other electrical assemblies requiring secure and precise board-to-board connections. Its robust design suits applications in manufacturing, laboratory testing setups, and HVAC control systems among others.
