Samtec SSQ Series Straight Through Hole PCB Socket, 19-Contact, 1 Row, 2.54 mm Pitch, Liquid Crystal Polymer SSQ-119-02-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 6.3A |
| Model | SSQ-119-02-T-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSQ |
| Termination Type | Through Hole |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 19 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Constructed with liquid crystal polymer housing for durability and performance.
- Phosphor bronze female contacts ensure reliable connectivity with matte tin plating.
- Designed for through hole mounting with a straight orientation suitable for board-to-board connection.
- Supports a current rating of 6.3 A and a voltage rating of 655 V.
- Operates within a temperature range of -55°C to 105°C for versatile application.
- Standard and low insertion force contact with 0.635 mm square tails provide secure self-nesting installation.
- Series SSQ connector system meets demanding industrial and electronic assembly requirements.
Product Description
Samtec SSQ-119-02-T-S PCB Socket is a high-quality electronic component designed for board-to-board connections in industrial and electronic applications. Featuring 19 female contacts arranged in a single row with a standard 2.54 mm pitch, this socket provides a reliable connection interface for through hole mounting.
The housing is made from liquid crystal polymer, delivering excellent mechanical strength and thermal stability. The contacts are manufactured from phosphor bronze with matte tin plating, offering resistance to corrosion and stable electrical performance over time.
Designed for use with a current rating of 6.3 A and a voltage rating of up to 655 V, this socket operates safely across a wide temperature range from -55°C to 105°C, ensuring robustness in harsh environments.
The low insertion force and standard contact design, with 0.635 mm square tails, enable easy and secure self-nesting applications on printed circuit boards. This makes the SSQ-119-02-T-S ideal for use in industrial electronics, manufacturing lines, electric assemblies, and laboratory equipment.
Constructed with liquid crystal polymer housing for durability and performance. Phosphor bronze female contacts with matte tin plating ensure long-lasting connectivity. Through hole mounting with straight orientation for board-to-board connection.
Supports 6.3 A current and 655 V voltage ratings. Operates effectively in temperatures between -55°C and 105°C. Standard and low insertion force contact design for easy installation. 19 contacts arranged in a single row with 2.54 mm pitch.
This PCB Socket is suitable for integration in electronic circuits requiring dependable connectivity. Its robust design and reliable contact materials make it an excellent choice for various electrical assemblies, industrial equipment, and commercial electronic products.
Explore more electronic components and connectors to support your projects at EnvMart for reliable and industry-standard products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 6.3 A and a voltage rating of up to 655 V.
The contacts are arranged with a pitch of 2.54 mm.
It features a housing made from liquid crystal polymer and female contacts made of phosphor bronze with matte tin plating.
The SSQ-119-02-T-S operates effectively within a temperature range of -55°C to 105°C.
This model has a total of 19 female contacts arranged in a single row.
It is designed for through hole mounting, which is suitable for board-to-board connections.
The contacts are arranged in a straight orientation.
The termination type is through hole, allowing for secure installation on printed circuit boards.
This model is classified as a socket strip.
The contacts are plated with tin, which provides resistance to corrosion and stable electrical performance over time.
It is ideal for use in industrial electronics, manufacturing lines, electric assemblies, and laboratory equipment.
The country of origin for this socket is India.
