Tedea Huntleigh Low Profile Stainless Steel Compression Load Cell, 5 kg to 100 kg Capacity, IP68, Model 0355-0100-G300-RS
Specifications
| Country of Origin | India |
|---|---|
| Display | screen |
| Brand | Tedea Huntleigh |
| Length | 120mm |
| Model | 0355-0100-G300-RS |
| IP Rating | IP68 |
| Sensor Type | Low Profile |
| Housing Material | Stainless Steel |
| Series | Model 355 |
| Termination Type | Cable |
| Maximum Operating Temperature | 40°C |
| Minimum Operating Temperature | -10°C |
| Terminal type | Wire |
| Maximum dc Voltage | 15V dc |
| Standards/Approvals | OIML, NTEP |
| Maximum AC Voltage | 15V ac |
| Force Measured | Compression |
| Maximum Force/Load Measurement | 100kg |
| Minimum Force/Load Measurement | 5kg |
| Ultimate Overload | 300% of Rated Load |
Key Features
- Constructed from high-grade stainless steel for durability and corrosion resistance.
- Low profile design enables installation in constrained spaces.
- Hermetically sealed with IP68 rating for harsh environment applications.
- Operates safely at temperatures between -10°C and 40°C.
- Uses a 3m 6-core screened cable for reliable connection and signal integrity.
- Rated to handle an ultimate overload of 300% of the specified load.
- Compatible with platform scales, hopper and tank weighing, test rigs, and general force measurement systems.
- Mounting facilitated via three 8 mm diameter holes ensuring secure installation.
Product Description
Tedea Huntleigh 0355-0100-G300-RS low profile load cell is engineered for accurate compression force measurement with capacities ranging from 5 kg minimum to 100 kg maximum. Constructed of welded stainless steel, this sensor features a low profile form factor measuring 120 mm in length and 32 mm in diameter, facilitating use in applications where space is limited.
It is hermetically sealed to IP68 standards, making it ideal for operation in harsh industrial environments including platform scales, hopper and tank weighing, general process weighing, test rigs, and various force measurement setups.
The load cell supports a maximum AC and DC voltage of 15 V, with an output impedance of 350 ± 3 Ω, ensuring reliable and precise signal transmission through its 3-meter, 6-core screened cable termination. Its ultimate overload capacity is rated at 300% of the rated load, providing excellent safety margin.
Operating temperature ranges from -10°C to +40°C ensure suitability for various industrial environments. Installation is secured through three 8 mm diameter mounting holes, promoting stability during demanding operations.
High-grade stainless steel housing for robust durability and corrosion resistance. Low profile design optimizes installation in limited space environments. Hermetic sealing rated IP68 for resistance against dust and water ingress.
Wide compensated temperature range maintains operational accuracy. High overload limit enhances safety and reliability in harsh conditions. Precise output impedance enhances signal quality for measurement systems. 3m screened cable termination supports secure wiring in industrial settings.
Universal mounting provisions with 3 x 8 mm holes enable versatile integration. This model complies with OIML and NTEP standards, demonstrating its suitability for reliable and certified measurement applications.
Ideal for industrial automation, manufacturing process control, laboratory testing, and commercial weighing applications. For more options, browse the full range of Load Cells on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This load cell can measure a maximum load of 100 kg.
It operates safely within a temperature range of -10°C to +40°C.
The load cell has an IP68 rating, indicating it is hermetically sealed for protection against dust and water ingress.
It is constructed from high-grade stainless steel, providing durability and corrosion resistance.
Installation is facilitated via three 8 mm diameter holes, ensuring secure mounting.
This load cell is designed to measure compression forces.
The output impedance is 350 ± 3 Ω, which supports reliable signal transmission.
The load cell measures 120 mm in length and has a diameter of 32 mm.
It supports a maximum AC and DC voltage of 15 V.
It complies with OIML and NTEP standards for reliable measurement applications.
It uses a 3-meter, 6-core screened cable for connection and signal integrity.
