Tedea Huntleigh Low Profile Alloy Tool Steel Load Cell 125 kg to 10000 kg Compression Measure IP67 Cable 65023-125K-NC-01F
Specifications
| Country of Origin | India |
|---|---|
| Brand | Tedea Huntleigh |
| Length | 25mm |
| Model | 65023-125K-NC-01F |
| Depth | 31mm |
| IP Rating | IP67 |
| Sensor Type | Low Profile |
| Width | 31mm |
| Housing Material | Alloy Tool Steel |
| Series | Model 65023 |
| Maximum Operating Temperature | 65°C |
| Minimum Operating Temperature | -18°C |
| Terminal type | Cable |
| Maximum dc Voltage | 15V dc |
| Standards/Approvals | NTEP Class III: 5000d, OIML R-60 3000d, NTEP IIIL, Ex ia IIC T4, IIIL: 10000d, Ex ia IIIC T135°C, III, II, Groups A through G, EEx ia IIC T6, NTEP III, Factory Mutual System Approved for Classes I, OIML R60, RoHS, Divisions 1 and 2 |
| Maximum AC Voltage | 15V ac |
| Force Measured | Compression |
| Maximum Force/Load Measurement | 10000kg |
| Minimum Force/Load Measurement | 125kg |
| Standards/ApprovalsNTEP Class III | 5000d, OIML R-60 3000d, NTEP IIIL, Ex ia IIC T4, IIIL: 10000d, Ex ia IIIC T135°C, III, II, Groups A through G, EEx ia IIC T6, NTEP III, Factory Mutual System Approved for Classes I, OIML R60, RoHS, Divisions 1 and 2 |
| NTEP Class III | 5000d, OIML R-60 3000d, NTEP IIIL, Ex ia IIC T4, IIIL: 10000d, Ex ia IIIC T135°C, III, II, Groups A through G, EEx ia IIC T6, NTEP III, Factory Mutual System Approved for Classes I, OIML R60, RoHS, Divisions 1 and 2 |
| Capacities | 50 to 10,000 kg (50 to 20,000 lbs) |
Key Features
- Constructed from alloy tool steel with nickel plating for durability.
- Provides high accuracy shear beam measurement for platform and pallet scales.
- Capable of measuring forces from 125 kg minimum up to 10,000 kg maximum.
- Features IP67 rating for full environmental sealing and reliability.
- Equipped with cable terminals and two additional sense wires for compensation.
- Operates within temperature range of -18°C to 65°C.
- Complies with multiple industry standards including NTEP Class III and OIML R-60.
- Suitable for compression, tension, suspended hoppers, overhead track scales, and force measurement.
Product Description
Tedea Huntleigh 65023-125K-NC-01F is a highly accurate low profile load cell constructed from alloy tool steel with nickel plating. It is specifically engineered to measure compression forces ranging from 125 kg up to 10,000 kg, making it ideal for applications like platform scales, pallet scales, and process weighing where precision and durability are critical.
The load cell features a shear beam sensor type with cable terminal connections and is protected with an IP67 rating ensuring excellent resistance against dust and water ingress. The robust casing and advanced environmental sealing extend the product's long-term reliability even in harsh industrial environments.
Operating temperature ranges between -18°C and 65°C support use in diverse settings. This model complies with multiple rigorous standards, including NTEP Class III with 5000d, OIML R-60 3000d, Ex ia certifications, and is Factory Mutual System Approved for hazardous classifications. Its trimmed output versions offer 2 or 3 mV/V sensitivity for precise load measurement with compensation for cable extensions and temperature variations via additional sense wires.
Typical applications include suspended hopper weighing, overhead track scales, and general force measurement in automation and control systems. The compact dimensions of 25 mm length, 31 mm width, and 31 mm depth allow for easy integration into custom weighing solutions.
Constructed from alloy tool steel with nickel plating for corrosion resistance. Low profile shear beam design for high accuracy and shock resistance. Wide capacity range from 125 kg to 10,000 kg for versatile use. Full environmental sealing with IP67 rating ensures durability.
Two additional sense wires allow compensation for cable resistance changes. Compatible with compression and tension applications. Suitable for industrial automation, manufacturing, and material handling sectors. Meets and exceeds major international certifications for safety and accuracy.
This load cell is an essential component for precision weighing and force measurement systems, backed by the reputable Tedea Huntleigh brand and designed to meet rigorous industrial standards. Explore other sensors and Load Cells in the EnvMart catalog for complementary products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can measure loads up to a maximum of 10,000 kg.
It is capable of measuring a minimum force of 125 kg.
The load cell has an IP67 rating, providing full environmental sealing against dust and water ingress.
It is constructed from alloy tool steel with nickel plating for corrosion resistance.
It operates within a temperature range of -18°C to 65°C.
This unit uses a low profile shear beam sensor type for high accuracy measurements.
The dimensions of this model are 25 mm in length, 31 mm in width, and 31 mm in depth.
It is equipped with cable terminal connections and includes two additional sense wires for compensation.
It complies with NTEP Class III, OIML R-60, and is Factory Mutual System Approved for hazardous classifications.
The maximum DC voltage rating for this model is 15V dc.
It features two additional sense wires that allow for compensation of cable resistance changes and temperature variations.
