HARWIN Datamate L-Tek Series Right Angle Through Hole PCB Header 20 Contacts 2 mm Pitch 2 Row Shrouded M80-8512042
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Right Angle |
| Current | 3A |
| Model | M80-8512042 |
| Mount Type | Through Hole |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | Datamate L-Tek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3mm |
Key Features
- Designed for through hole mounting on PCBs for robust connections.
- Constructed with polyphenylene sulphide housing for durability.
- Utilizes phosphor bronze contacts plated with gold for reliable conductivity.
- Rated for currents up to 3A and 120V operation.
- Operates in a wide temperature range from -55°C to 125°C.
- Features a 3 mm tail pin length suited for solder termination.
- Right angle orientation suitable for board-to-board and wire-to-board applications.
- Shrouded for protection against shorts and enhanced mechanical stability.
Product Description
HARWIN M80-8512042 is a robust Datamate L-Tek Series PCB Header designed for high reliability electronic applications. This right angle through hole header features 20 male contacts arranged in 2 rows with a 2 mm pitch, optimized for secure board-to-board and wire-to-board connections.
The housing is made from polyphenylene sulphide, providing durable insulation and resistance to harsh conditions, while the phosphor bronze contacts with gold plating ensure excellent electrical conductivity and corrosion resistance. With a current rating of 3A and voltage capacity of 120V, this header is suitable for demanding industrial, laboratory, and manufacturing electronics.
Engineered to operate between -55°C and 125°C, it withstands wide temperature extremes commonly encountered in electronic devices. The 3 mm tail pin length supports solder termination, facilitating reliable PCB mounting. The shrouded design and right angle orientation enhance mechanical protection and enable space-saving configurations on circuit boards.
Manufactured to meet stringent quality requirements in the United Kingdom, this header complies with industry standards such as BS9525-F0033 and MIL C 55302, making it ideal for commercial off-the-shelf (COTS) applications where safety and durability are critical.
Designed for through hole mounting on PCBs for robust connections. Constructed with polyphenylene sulphide housing for durability. Utilizes phosphor bronze contacts plated with gold for reliable conductivity. Rated for currents up to 3A and 120V operation.
Operates in a wide temperature range from -55°C to 125°C. Features a 3 mm tail pin length suited for solder termination. Right angle orientation suitable for board-to-board and wire-to-board applications. Shrouded for protection against shorts and enhanced mechanical stability.
Manufactured in the United Kingdom ensuring quality standards. Ideal for electronic components requiring high reliability in harsh environments.
This HARWIN PCB header is suitable for a variety of applications in industrial, laboratory, manufacturing, and HVAC electronics where secure and durable PCB connections are essential. Explore the broad range of HARWIN components on EnvMart for dependable electronic connector solutions.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 3A and a voltage capacity of 120V.
It operates within a temperature range of -55°C to 125°C.
The housing is made from polyphenylene sulphide, and the contacts are phosphor bronze plated with gold.
It features 20 male contacts arranged in 2 rows with a 2 mm pitch.
This unit uses solder termination with a 3 mm tail pin length.
This header has a right angle orientation, suitable for board-to-board and wire-to-board applications.
Yes, it is shrouded, which provides protection against shorts and enhances mechanical stability.
It is manufactured in the United Kingdom, ensuring adherence to quality standards.
It is suitable for industrial, laboratory, manufacturing, and HVAC electronics requiring secure PCB connections.
This header complies with industry standards such as BS9525-F0033 and MIL C 55302.
It supports board-to-board and wire-to-board connector systems.
The contacts are arranged with a pitch of 2 mm.
