HARWIN Datamate L-Tek Series Right Angle Surface PCB Header 10 Contact 2 mm Pitch 2 Row Shrouded M80-8281042

Free Delivery in India | Lowest Global Shipping Charges

HARWIN Datamate L-Tek Series Right Angle Surface PCB Header 10 Contact 2 mm Pitch 2 Row Shrouded M80-8281042

Name: HARWIN Datamate L-Tek Series Right Angle Surface PCB Header 10 Contact 2 mm Pitch 2 Row Shrouded M80-8281042
Brand: HARWIN
SKU: 164636



Category PCB Headers Brand HARWIN Condition New

Specifications

Country of Origin	United Kingdom
Voltage	120V
Brand	HARWIN
Orientation	Right Angle
Current	3A
Model	M80-8281042
Mount Type	Surface
Housing Material	Polyphenylene Sulphide
Contact Material	Phosphor Bronze
Series	Datamate L-Tek
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2mm
Contact Plating	Gold
Number of Contacts	10
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board

Key Features

The housing is made of durable Polyphenylene Sulphide ensuring mechanical strength.
It supports a current rating of 3A suitable for moderate power applications.
Contacts are male gender with phosphor bronze material and gold plating for excellent conductivity.
The connector is surface mount type with right angle orientation and shrouded latch design.
Operating temperature ranges from -55°C to 125°C for harsh environments.
It is designed for board-to-board and wire-to-board connector systems.
The termination is solder type, ensuring secure electrical connections.
This component complies with various industrial standards for reliability but has no certifications listed.

Product Description

HARWIN M80-8281042 Datamate L-Tek Series Right Angle Surface PCB Header is a precision connector designed for electronic devices requiring secure, high-reliability board interconnections. With a 2 mm pitch and 10 male contacts arranged in 2 rows, it offers efficient connection for demanding applications requiring up to 3A current capacity.

Manufactured in the United Kingdom, the housing utilizes high-quality Polyphenylene Sulphide material providing excellent durability and resistance to mechanical stress. The contacts are made from phosphor bronze and plated with gold to ensure long-lasting conductivity and resistance to corrosion.

The right angle orientation facilitates board-to-board and wire-to-board connections, making it adaptable for compact PCB designs. The shrouded design adds protection to the contacts and prevents mis-mating. This header supports solder termination, providing secure electrical and mechanical retention on the PCB.

Operating reliably in temperatures between -55°C and 125°C, it suits harsh industrial and commercial applications including electronics manufacturing, test and measurement equipment, and communication devices.

The connector system supports latched mating to withstand vibration and mechanical stress. Polarised mouldings and robust four-finger beryllium copper contacts ensure consistent electrical connections even under severe conditions.

Designed for durability over many mating cycles without performance degradation. Compatible with industry-known equivalents and suitable for commercial off-the-shelf (COTS) applications. Complies with standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008 ensuring quality and reliability in use.

This product is ideal for use in industrial, laboratory, manufacturing, and electronic assembly line contexts requiring robust PCB Headers.
