HARWIN Datamate L-Tek Series Right Angle Surface PCB Header 16 Contacts 2 mm Pitch 2 Row Shrouded M80-8281642

HARWIN M80-8281642 is a right angle surface mount PCB header from the Datamate L-Tek series, featuring 16 contacts arranged in 2 rows with a 2 mm pitch. This shrouded connector is engineered for high reliability in demanding industrial and electronic applications.

The connector housing is constructed from durable Polyphenylene Sulphide material ensuring mechanical strength and thermal stability. Contacts are made of high-quality phosphor bronze and plated with gold to enhance electrical conductivity and resist corrosion over repeated mating cycles. Its current capacity of 3 amperes and voltage rating of 120 volts make it suitable for moderate power electronic circuits.

Designed for harsh environments, it operates reliably within a temperature span from -55°C up to 125°C, making it ideal for applications exposed to wide temperature variations. The right angle orientation facilitates efficient routing and compact PCB layouts, commonly seen in telecommunications, industrial control systems, and automotive electronics.

This L-Tek series connector includes polarization features through its shrouded design which prevents incorrect mating and ensures secure connections. It supports board-to-board and wire-to-board connection systems and employs a surface mount termination type optimized for SMT assembly processes, enhancing manufacturing efficiency.

The Datamate series is known for its resilience against vibration and shock, making this connector ideal for equipment subject to mechanical stress such as aerospace, military, and ruggedized electronics. Although it has no formal certifications listed, its robust design aligns with industry standards including BS9525-F0033, MIL C 55302, and CEC 75101-008 equivalences, providing trusted performance.

The product is made in the United Kingdom and comes in new condition, suitable for professional use in industrial, manufacturing, and laboratory electronic assembly applications. Series: Datamate L-Tek designed for high reliability and durability.

Current rating of 3A ensures efficient power handling. Housing made of Polyphenylene Sulphide for robustness. Contacts are phosphor bronze plated with gold for corrosion resistance. Operates within -55°C to 125°C temperature range.

Right angle orientation suitable for space-constrained PCB layouts. Shrouded design provides protection and polarization. Surface mount type optimizes PCB assembly and soldering. Compatible with board-to-board and wire-to-board connector systems.
