Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header 12 Contacts 3 mm Pitch 2 Row Shrouded 43045-1211
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 8.5A |
| Mount Type | Surface |
| Housing Material | Thermoplastic |
| Contact Material | Brass |
| Series | Micro-Fit 3.0 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 3mm |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- The header features a shrouded design enhancing durability and protection.
- Thermoplastic housing material ensures heat resistance and sturdiness.
- Rated for 8.5A current and 600V voltage operation.
- Gold-plated brass contacts for optimal conductivity and corrosion resistance.
- Operates efficiently in temperatures ranging from -40°C to 125°C.
- Right angle orientation aligns connections for space-saving PCB layouts.
- Designed for surface mounting with solder termination for secure attachment.
- Suitable for industrial electronic applications requiring reliable PCB connections.
Product Description
Molex 43045-1211 Micro-Fit 3.0 Series Right Angle Surface PCB Header offers a robust and efficient wire-to-board connection solution with 12 contacts arranged in a dual row, spaced at 3 mm pitch. Featuring a shrouded configuration and thermoplastic housing, this header ensures enhanced mechanical stability and electrical insulation.
The brass contacts with gold plating provide excellent conductivity and resistance to corrosion, supporting a current rating of 8.5A and voltage rating of 600V, suitable for demanding industrial electronics, HVAC systems, manufacturing equipment, and laboratory instrumentation.
Its right angle design supports compact PCB layouts while the surface mount and solder termination provide reliable and durable assembly. The header is engineered to operate under extreme temperatures from -40°C to 125°C, making it ideal for diverse environmental conditions.
These technical features make the Molex 43045-1211 an excellent choice for power and signal connections on printed circuit boards requiring reliable, high-performance connectors with glow-wire capability.
The header features a shrouded design enhancing durability and protection. Thermoplastic housing material ensures heat resistance and sturdiness. Rated for 8.5A current and 600V voltage operation. Gold-plated brass contacts for optimal conductivity and corrosion resistance.
Operates efficiently in temperatures ranging from -40°C to 125°C. Right angle orientation aligns connections for space-saving PCB layouts. Designed for surface mounting with solder termination for secure attachment. Suitable for industrial electronic applications requiring reliable PCB connections.
Explore EnvMart's range of PCB Headers and electronic connectors for high-reliability connectivity solutions suited for electronics manufacturing, industrial automation, and embedded system designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 8.5A.
It has a voltage rating of 600V.
The contacts are arranged with a pitch of 3 mm.
This unit uses solder termination for secure attachment.
It operates efficiently in temperatures ranging from -40°C to 125°C.
It features 12 contacts arranged in a dual row.
The housing is made from thermoplastic material, ensuring heat resistance and sturdiness.
This model has a right angle orientation, which helps in space-saving PCB layouts.
The contacts are made of brass and are gold-plated for optimal conductivity and corrosion resistance.
Yes, it is designed for industrial electronic applications requiring reliable PCB connections.
The country of origin for this product is Mexico.
It is designed for surface mounting, which allows for secure attachment to the PCB.
