Nexperia 1.5 V 5.1 V Zener Diode Single 500 mW 2% Surface Mount 2-Pin SOD-80 BZV55-B5V1,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1.5 V 5.1 V Zener Diode Single 500 mW 2% Surface Mount 2-Pin SOD-80 BZV55-B5V1,115

Name: Nexperia 1.5 V 5.1 V Zener Diode Single 500 mW 2% Surface Mount 2-Pin SOD-80 BZV55-B5V1,115
Brand: Nexperia
SKU: 164497
Price: 0.05 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.6mm
Length	3.7mm
Model	BZV55-B5V1,115
Mount Type	Surface
Series	BZV55
Maximum Operating Temperature	200°C
Package Type	SOD-80
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	2μA
Nominal Zener Voltage Vz	5.1V
Zener Type	Voltage Regulator
Maximum Zener Impedance	60Ω
Typical Voltage Temperature Coefficient	-0.8mV/°C
onsemi 1, 5.1 V Zener Diode, Single 500 mW 5 % Through Hole 2-Pin SOD-27Brand	onsemi

Key Features

Provides voltage regulation with a tight tolerance of ±2%.
Surface mount package type SOD-80 with 2 pins for easy PCB integration.
Operates at a test current of 5 mA with maximum Zener impedance of 60 ohms.
Features low maximum reverse leakage current of 2 microamperes for better efficiency.
Wide operating temperature range from -65°C to 200°C suitable for various industrial applications.
Compact dimensions with length of 3.7 mm and height of 1.6 mm.
Typical voltage temperature coefficient of -0.8 mV/°C for stable performance in temperature variations.
New product condition and manufactured in China.

Product Description

Nexperia BZV55-B5V1,115 is a high-quality surface mount Zener diode designed for voltage regulation in electronic circuits. It features a nominal Zener voltage of 5.1 volts with low tolerance of ±2%, ensuring reliable and precise voltage regulation for sensitive semiconductor applications.

This single diode in a compact SOD-80 2-pin package supports a maximum power dissipation of 500 mW and operates effectively over a wide temperature range from -65°C to 200°C, making it suitable for automotive, industrial, and consumer electronics environments.

The device has a low maximum reverse leakage current of 2 microamperes and a maximum Zener impedance of 60 ohms at a test current of 5 mA, which contributes to its energy efficiency and long-term stability under operational conditions.

With dimensions of 3.7 mm length and 1.6 mm height, it supports surface mount technology (SMT) for compact PCB layouts. The typical voltage temperature coefficient of -0.8 mV/°C helps maintain voltage stability under temperature fluctuations.

This Zener diode is part of the BZV55 series by Nexperia, manufactured in China, and supplied in new condition for assured quality and performance. Provides voltage regulation with precise ±2% tolerance. Compact surface mount SOD-80 package for efficient PCB layout.

High maximum power dissipation of 500 mW for robust applications. Wide temperature operation from -65°C to 200°C for varied environments. Low reverse leakage current for improved energy efficiency. Reliable performance confirmed by test current and impedance levels.

Ideal for industrial, automotive, and consumer electronic use cases.

This product is suitable for electronic designers requiring a stable and durable voltage regulation diode. Browse EnvMart's wide electronics components catalog for further power and semiconductor solutions from Nexperia and other leading brands.
