Samtec Right Angle Through Hole PCB Socket, 40-Contact, 2 Row, 0.55 mm Pitch, 21.8A Current, 220V QSH-020-01-L-D-DP-A-K-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 220V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 21.8A |
| Model | QSH-020-01-L-D-DP-A-K-TR |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | QSH-RA |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Right Angle Ground Plane |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 0.55mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 40 |
| Connector System | Board-to-Board |
Key Features
- Features a 0.55 mm pitch for tight and efficient board layouts.
- Supports a current rating of 21.8A for demanding electrical applications.
- Constructed with liquid crystal polymer housing for durability and thermal stability.
- Includes gold-plated phosphor bronze contacts to ensure excellent conductivity and corrosion resistance.
- Suitable for board-to-board connector systems requiring secure solder termination.
- Operates reliably between -55°C and 125°C temperature range.
- Designed with right angle orientation for easy PCB interfacing.
- Complies with RoHS directives for environmental safety.
Product Description
Samtec QSH-020-01-L-D-DP-A-K-TR is a right angle through hole PCB socket designed for reliable and high-performance electronic connections. Featuring 40 contacts arranged in 2 rows with a compact 0.55 mm pitch, this connector is ideal for applications requiring tight board spacing and precision.
The socket housing is made from robust liquid crystal polymer, providing excellent thermal resistance and mechanical stability. Phosphor bronze contacts plated with gold ensure optimal electrical conductivity and longevity, making it well-suited for demanding industrial and electronic manufacturing use.
This connector is designed for solder termination on PCB and supports a current rating of 21.8A and voltage rating of 220V, suitable for various board-to-board connection systems. It operates effectively within a wide temperature range from -55°C to 125°C, ensuring reliable performance in diverse environmental conditions.
The QSH-RA series by Samtec meets RoHS standards, underscoring its compliance with environmental regulations. Its right angle orientation facilitates efficient assembly in dense PCB layouts, widely used in industrial electronics, manufacturing, communications, computing, and laboratory equipment.
0.55 mm pitch for precise and compact connections. 40 contacts arranged in 2 rows for multi-point connectivity. High current capacity of 21.8A for power applications. Durable liquid crystal polymer housing. Gold-plated phosphor bronze contacts for corrosion resistance.
Right angle through hole mount type for PCB installation. Wide temperature operating range from -55°C to 125°C. RoHS compliant ensuring environmental safety.
This PCB socket is ideal for electronics manufacturing, industrial automation, telecommunications equipment, and laboratory instrumentation where reliable and compact connectors are essential. Explore the Electronics & Electricals > Electronics Components > PCB Sockets category for additional compatible connectors and accessories at EnvMart.
