Samtec Right Angle Through Hole PCB Socket 40-Contact 2 Row 0.55 mm Pitch Solder QSH-020-01-H-D-DP-A

Samtec presents the QSH-020-01-H-D-DP-A model, part of the QSH-RA series right angle through hole PCB sockets designed specifically for high-speed board-to-board connectivity. This connector features 40 contacts arranged in 2 rows with a compact 0.55 mm pitch. It provides excellent electrical performance and mechanical stability, ideal for use in demanding electronic applications.

The socket utilizes a liquid crystal polymer housing material that offers enhanced durability and thermal stability, capable of withstanding operating temperatures from -55°C up to 125°C. Contacts are made of phosphor bronze and plated with gold to reduce contact resistance and prevent corrosion, ensuring a long service life.

This PCB socket supports a maximum current of 21.8 amperes at an operating voltage of 220 volts, making it suitable for power and connector applications across various industrial and manufacturing sectors.

The right angle orientation and through hole mounting allow for secure fixation on the printed circuit board, facilitating reliable mechanical connection and ease of assembly. The series is engineered with differential pair provisions and ground plane features to optimize signal integrity in high-speed data transmissions.

Certified to comply with RoHS standards, this socket supports environmentally conscious manufacturing processes. It is well-suited for use in electronics, electrical equipment, and power connector assemblies in industrial, laboratory, and commercial environments.

Designed for high-speed board-to-board connections with right-angle orientation. Constructed with a liquid crystal polymer housing for durability and stability. Gold-plated phosphor bronze contacts ensure reliable electrical performance.

Supports a current rating of 21.8A at 220V operating voltage. Operates reliably in temperatures ranging from -55°C to 125°C. Features a 0.55 mm pitch spacing suitable for compact PCB layouts. Series QSH-RA ground plane socket with differential pair capability.

Through hole mount facilitates secure mechanical and electrical installation. Meets RoHS standards for environmental compliance. Ideal for electronic components, power and connectors applications requiring robust PCB sockets.

Explore this product and our broad range of PCB Sockets and connectors on EnvMart for diverse industrial applications.
