Samtec Straight Surface PCB Header 6 Contact 1 mm Pitch 1 Row Shrouded T1M-06-F-SH-L-K
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.3A |
| Model | T1M-06-F-SH-L-K |
| Mount Type | Surface |
| Housing Material | Natural LCP |
| Contact Material | Phosphor Bronze |
| Series | T1M |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -10°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Silver, Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- This PCB header features 6 contact pins with a 1 mm pitch.
- Constructed with a natural LCP housing for durability.
- Phosphor bronze contacts plated with silver and tin ensure reliable conductivity.
- Supports a current rating of 3.3A per pin.
- Designed for surface mount on PCBs with a straight orientation.
- Shrouded design provides enhanced protection and precise alignment.
- Operational temperature range from -10°C to 85°C.
- Termination type is solder, with male contact gender.
Product Description
Samtec T1M-06-F-SH-L-K PCB Header is a straight, surface mount connector designed for reliable wire-to-board connections in electronic applications. It belongs to the T1M series featuring a 1 mm pitch and 6 contact pins arranged in a single row. The connector is shrouded to protect contacts during mating and ensure precise alignment.
The housing is made from natural Liquid Crystal Polymer (LCP), which provides excellent durability and stability in demanding environments. Contacts are crafted from phosphor bronze for optimal electrical conductivity and plated with silver and tin to prevent corrosion and enhance performance.
This header supports a rated current of 3.3 amperes per pin and operates safely up to 250 volts AC or 353 volts DC. It functions effectively within a temperature range from -10 degrees Celsius to 85 degrees Celsius, making it suitable for standard industrial and commercial electronics.
The surface mount design facilitates easy installation onto printed circuit boards, and its straight orientation is compatible with a variety of wire-to-board connection requirements. The termination type is solder, and it features male contacts.
This PCB Header features 6 contact pins with a 1 mm pitch. Constructed with a natural LCP housing for durability. Phosphor bronze contacts plated with silver and tin ensure reliable conductivity. Supports a current rating of 3.3A per pin.
Designed for surface mount on PCBs with a straight orientation. Shrouded design provides enhanced protection and precise alignment. Operational temperature range from -10°C to 85°C. Voltage rating up to 250 VAC/353 VDC. Termination type is solder, with male contact gender.
Suitable for industrial and electronic manufacturing applications.
This connector is widely used in industrial plants, electronic manufacturing, telecommunications, and consumer electronics where secure, high-performance PCB connections are needed. Its mechanical and electrical properties meet demanding application requirements for durability and safety.
Browse the Electronics & Electricals category at EnvMart for more PCB connectors and electronic components from Samtec and other leading brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 3.3A per pin.
The voltage rating for this model is up to 250 volts AC or 353 volts DC.
It operates effectively within a temperature range from -10°C to 85°C.
The termination type for this header is solder, with male contact gender.
This model features 6 contact pins arranged in a single row.
The housing is made from natural Liquid Crystal Polymer (LCP), and the contacts are made of phosphor bronze plated with silver and tin.
The pitch size of this header is 1 mm.
Yes, it is designed for surface mount on printed circuit boards (PCBs).
The orientation of this model is straight.
It is suitable for industrial and electronic manufacturing applications, telecommunications, and consumer electronics.
The country of origin for this product is India.
The shrouded design provides enhanced protection for the contacts during mating and ensures precise alignment.
