Samtec SSW Series Straight Through Hole PCB Socket 16-Contact 1 Row 2.54 mm Pitch Through Hole Solder Tail SSW-116-01-F-S

Free Delivery in India | Lowest Global Shipping Charges

Samtec SSW Series Straight Through Hole PCB Socket 16-Contact 1 Row 2.54 mm Pitch Through Hole Solder Tail SSW-116-01-F-S

Name: Samtec SSW Series Straight Through Hole PCB Socket 16-Contact 1 Row 2.54 mm Pitch Through Hole Solder Tail SSW-116-01-F-S
Brand: Samtec
SKU: 162701
Price: 2.59 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	655V
Brand	Samtec
Orientation	Straight
Current	4.7A
Model	SSW-116-01-F-S
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Current Rating	4.7A per pin(2 pins powered)
Series	SSW
Termination Type	Through Hole
Maximum Operating Temperature	125°C
Sub Type	Solder Tail
Minimum Operating Temperature	-55°C
Number of Rows	1
Max Cycles	100 with 10μ" (0.25μm)
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	16
Contact Gender	Female
Connector System	Board-to-Board

Key Features

The socket features a liquid crystal polymer housing for excellent durability.
Phosphor bronze contacts are gold plated for high conductivity and corrosion resistance.
It supports a voltage rating up to 655V and a current rating of 4.7A per contact (2 pins powered).
Designed to operate reliably between -55°C and 125°C temperature range.
Termination is through-hole type for robust PCB attachment.
Standard normal force of 125 grams ensures consistent contact pressure.
Maximum cycle life is 100 with 10 microinches gold plating thickness.
The connector system is optimized for board-to-board connections.

Product Description

Samtec SSW-116-01-F-S is a high-quality Straight Through Hole PCB Socket designed for demanding electronic applications. With 16 contacts arranged in a single row and a standard 2.54 mm pitch, this socket is built for easy and reliable solder tail mounting on printed circuit boards.

Its liquid crystal polymer housing ensures excellent mechanical strength and heat resistance, making it suitable for harsh industrial environments. The phosphor bronze contacts feature gold plating, providing high conductivity, durability, and corrosion resistance essential for long-term performance.

Rated for a voltage of 655V and capable of carrying 4.7A current per pin (considering 2 pins powered), this socket meets strong electrical requirements for various industrial, laboratory, and manufacturing PCB connection needs. It can reliably operate from -55°C up to 125°C, making it versatile across temperature-sensitive applications.

The through-hole termination type guarantees a solid and firm mechanical attachment to PCB substrates, perfect for board-to-board connector systems. The standard contact normal force of 125 grams delivers consistent engagement strength, while the maximum cycling capability with 10 microinches of gold plating is rated at 100 cycles, assuring longevity in repeated connection scenarios.

This Samtec SSW series socket is commonly used in electronics manufacturing, testing setups, telecommunications equipment, and other industrial PCB interconnects requiring precise, reliable connections.

The housing material is a durable liquid crystal polymer. Contact material is phosphor bronze with gold plating. Voltage rating up to 655V supports varied applications. Current rating of 4.7A per pin enhances performance.

Temperature range from -55°C to 125°C covers industrial standards. Standard normal force ensures stable contact pressure. Through-hole solder tail mounting provides strong PCB attachment. Connector system designed for board-to-board connections.

Choose Samtec SSW-116-01-F-S for top-tier PCB socket reliability and performance. Explore more PCB Sockets and connectors in the Electronics Components category at EnvMart.
