Samtec SS Series Straight Through Hole PCB Socket 5-Contact Single Row 2.54 mm Pitch Solder Termination SS-105-G-2
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Model | SS-105-G-2 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Beryllium Copper Alloy |
| Series | SS |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Standard Single Row |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Operating temp range | -55°C to +125°C |
| Lead-free solderable | wave only |
Key Features
- Precision machined with beryllium copper alloy contacts for durability.
- Gold-plated contacts provide excellent conductivity and corrosion resistance.
- Housing made from liquid crystal polymer ensuring thermal stability.
- Designed for through hole mounting with straight orientation for board-to-board connection.
- Supports operating temperature range from -55°C to 125°C.
- Compatible with wave soldering processes for lead-free soldering.
- Standard single row socket suitable for applications up to 32 positions.
- Complies with RoHS environmental standards.
Product Description
Samtec SS-105-G-2 is a high-precision PCB socket from the SS Series, featuring a straight through hole design with 5 female contacts arranged in a single row. It has a 2.54 mm pitch and is designed for solder termination, making it suitable for reliable board-to-board connections in electronic assemblies.
The socket contacts are made of beryllium copper alloy, offering excellent electrical conductivity and mechanical strength. These contacts are gold-plated to ensure superior corrosion resistance and consistent electrical performance, even in demanding industrial environments. The housing is constructed from liquid crystal polymer, providing outstanding thermal resistance and dimensional stability over an operating temperature range from -55°C up to 125°C.
This connector is designed for through hole mounting and is compatible with wave soldering processes, including lead-free soldering (wave only). Its straight orientation facilitates easy integration on printed circuit boards, supporting single row configurations up to 32 positions for versatile application requirements.
The SS Series socket complies with RoHS standards, making it environmentally friendly and compliant with current regulations. The female contact gender supports secure and reliable connections with mating components, suitable for electronic, industrial, and manufacturing applications requiring precise, durable PCB interconnections.
This product is ideal for use in electronics manufacturing, industrial equipment, communication devices, and any application requiring robust board-to-board connector solutions. The Samtec SS-105-G-2 PCB socket provides precision, durability, and performance for professional-grade electronics assembly.
Precision machined beryllium copper alloy contacts for durability. Gold plating enhances conductivity and corrosion resistance. Liquid crystal polymer housing for thermal stability. Through hole mounting with straight orientation.
Operating temperature range from -55°C to 125°C. Lead-free solderable using wave soldering technique. Standard single row design for up to 32 positions. Complies with RoHS environmental standards. Female contact gender for reliable mating.
Explore the Electronics Components category on EnvMart for compatible PCB Sockets and connectors from Samtec and other trusted brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB socket is 2.54 mm, which is standard for many electronic applications.
The maximum operating temperature for the SS-105-G-2 is 125°C.
The contacts are made from beryllium copper alloy and are gold-plated to enhance conductivity and corrosion resistance.
This model features 5 female contacts arranged in a single row.
Yes, it is compatible with lead-free soldering processes, specifically designed for wave soldering.
The SS-105-G-2 is designed for through hole mounting, facilitating board-to-board connections.
This socket has a straight orientation, which aids in easy integration on printed circuit boards.
The minimum operating temperature for the SS-105-G-2 is -55°C.
The housing is made from liquid crystal polymer, which provides thermal stability.
Yes, it complies with RoHS environmental standards, making it suitable for environmentally friendly applications.
This model utilizes a board-to-board connector system, suitable for various electronic applications.
The SS-105-G-2 is designed to support configurations up to 32 positions.
