Samtec ESW Series Vertical Through Hole Board-to-Board PCB Socket 5-Contact 1 Row 2.54 mm Pitch 5.2A ESW-105-23-T-S

Samtec ESW-105-23-T-S is a vertical through hole PCB socket from the ESW series, designed for board-to-board connections with 5 contacts arranged in a single row and a 2.54 mm pitch. It supports a current rating of 5.2A per pin and a voltage rating of 515V, suitable for various electronic component assemblies and industrial PCB usage.

The socket features a black glass filled polyester housing material providing mechanical strength and electrical insulation. Its contacts are constructed from phosphor bronze, plated with matt tin to ensure enhanced conductivity and resistance to corrosion.

Its solder termination type and through hole mount type make it compatible with standard PCB assembly processes requiring vertical orientation. The socket withstands a wide operating temperature range from -55°C up to 105°C, making it reliable for industrial and laboratory environments.

Normal insertion force strength of 125 grams (4.4N) ensures secure connectivity without excessive wear or damage to the contacts during assembly and maintenance operations. This socket complies with RoHS standards, reflecting its environmentally responsible manufacturing.

The ESW-105-23-T-S socket features 5 contacts in 1 row with a 2.54 mm pitch for precise and compact PCB connection. Black glass filled polyester housing provides reliable insulation and mechanical durability. Phosphor bronze contacts with matt tin plating offer excellent electrical performance and corrosion resistance.

Through hole, vertical mount configuration facilitates integration in various PCB layouts. Operating temperature range of -55°C to 105°C suits diverse industrial applications. Rated current of 5.2A and voltage of 515V support demanding electronic assemblies.

Meets RoHS compliance for environmentally safe usage and disposal.

This PCB Socket is widely applicable in industrial, manufacturing, electronics design, and PCB prototyping and repair scenarios. It supports robust and consistent electrical connections critical to device reliability across many sectors.

Search EnvMart’s extensive PCB connectors category for compatible accessories and related components to complement this Samtec ESW Series socket selection.
