Samtec ESQ Series Straight Through Hole PCB Socket, 8-Contact, 1 Row, 2.54 mm Pitch, 5.2A Current Rating ESQ-108-13-T-S
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Current | 5.2A |
| Model | ESQ-108-13-T-S |
| Mount Type | Through Hole |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | ESQ |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold over Tin |
| Number of Contacts | 8 |
Key Features
- Designed for board-to-board connections with solder termination.
- Offers a continuous current rating of 5.2 amperes per contact.
- Constructed with black glass-filled polyester housing for durability.
- Contacts made from phosphor bronze with gold over tin plating for reliable conductivity.
- Operates efficiently within a temperature range of -55°C to 125°C.
- Through hole mount type with straight orientation ensures stable mechanical and electrical connection.
- Complies with RoHS standards ensuring environmental safety.
- Part of the ESQ series trusted for PC/104 elevated socket applications.
Product Description
Samtec ESQ-108-13-T-S is a robust Straight Through Hole PCB Socket designed for reliable electronic interconnections in industrial and commercial applications. This connector features 8 contacts arranged in a single row with a 2.54 mm pitch, optimized for board-to-board assembly through solder termination.
The housing is manufactured from black glass-filled polyester, providing excellent insulation and mechanical strength suitable for demanding electronic environments. Contacts are crafted from phosphor bronze and plated with gold over tin to ensure excellent electrical conductivity and corrosion resistance over time and usage cycles.
Rated for a current capacity of 5.2 amperes per pin, this socket supports high-performance circuits requiring dependable current handling. The operating temperature range is wide, spanning from -55°C to 125°C, making it viable for a variety of industrial, manufacturing, and laboratory electronics applications.
The through hole, straight orientation mounting ensures secure and durable placement on printed circuit boards. Compliant with RoHS regulations, this product aligns with environmental directives for lead-free and hazardous substance-free electronic components.
Board-to-board solder termination enhances circuit reliability. Durable black glass-filled polyester housing ensures long service life. Phosphor bronze contacts with gold over tin plating guarantee stable electrical signals.
Wide operating temperature range for diverse environments. Supports currents up to 5.2A per contact for power demanding circuits. Through hole mount with straight orientation facilitates easy PCB integration. Meets RoHS standards for environmental compliance.
Part of the ESQ series suited for PC/104 elevated socket applications.
This product is suitable for use in electronics manufacturing, industrial control systems, telecommunications, and other precision electronic equipment requiring reliable PCB connections.
Shop with confidence for your specialized electronic connector needs at EnvMart, where quality and technical precision meet.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a continuous current rating of 5.2 amperes per contact, making it suitable for high-performance circuits.
The contacts are arranged with a pitch of 2.54 mm, which is standard for many board-to-board applications.
It features a housing made from black glass-filled polyester and contacts made from phosphor bronze, plated with gold over tin for reliable conductivity.
The ESQ-108-13-T-S operates efficiently within a temperature range of -55°C to 125°C, suitable for diverse environments.
This model features 8 contacts arranged in a single row, optimized for board-to-board connections.
It utilizes solder termination, which enhances circuit reliability during assembly.
This unit has a straight orientation, ensuring stable mechanical and electrical connections on printed circuit boards.
Yes, it complies with RoHS standards, ensuring it is free from lead and hazardous substances.
It is designed for through hole mounting, facilitating easy integration onto PCBs.
This model is part of the ESQ series, which is trusted for PC/104 elevated socket applications.
The country of origin for this product is India.
It is suitable for use in electronics manufacturing, industrial control systems, telecommunications, and precision electronic equipment requiring reliable PCB connections.
