Cinch Straight Edge Connector PCB 18-Contacts 2.54 mm Pitch 2 Row Solder BA000010000AE00

Cinch BA000010000AE00 Straight Edge Connector is a high-quality PCB edge connector with 18 contacts featuring a 2.54 mm pitch and 2-row arrangement soldered for secure electrical connections. This connector is designed for electronic and electrical components, providing reliable performance in industrial, laboratory, and manufacturing environments.

The contacts are made of brass with gold over nickel plating to enhance conductivity and resist oxidation. The housing is constructed from fibreglass reinforced polyethylene terephthalate, offering excellent mechanical strength and insulation. This product operates efficiently within a temperature range of -55°C to 105°C, making it suitable for various temperature-critical applications.

Its straight orientation and polarising key ensure correct and secure mating, preventing mismatches in PCB assembly. Rated for 3 amperes of current, it supports moderate electrical loads typically required in power connectors and electronic equipment. The solder termination type is compatible with standard PCB soldering processes, facilitating easy integration.

This edge connector complies with UL94V-0 rated polyester insulation, promoting safety in demanding environments. Manufactured in the United States, it meets industry expectations for quality and durability. Typical applications include use in computing, industrial controls, telecommunications, and other hardware requiring edge connector interfaces.

18 gold over nickel plated contacts ensure reliable conductivity. Double row configuration for robust connection. 2.54 mm pitch suits standard PCB spacing. Brass contact material for durability and corrosion resistance. Fibreglass reinforced polyethylene terephthalate housing for insulation and mechanical strength.

Operating temperature range from -55°C to 105°C for versatile applications. Solder termination type compatible with standard PCB assembly processes. Polarising key included to prevent incorrect mating. Rated for 3A current to support typical electronic loads.

Designed and manufactured in the United States. Explore more Edge Connectors and related electronic components at EnvMart for industrial, manufacturing, and electronic design needs.
