TE Connectivity Free Height Series Straight Surface PCB Header 100 Contact 0.8 mm Pitch 2 Row Shrouded 5179029-4

TE Connectivity 5179029-4 Free Height Series Straight Surface PCB Header is a high-density board-to-board connector featuring 100 contacts arranged in 2 rows with a 0.8 mm pitch. Designed for surface mount applications, this shrouded male header offers a compact and reliable connection solution for electronic assemblies requiring miniature packaging and parallel board stacking.

This header supports up to 500V and 500mA, making it suitable for low power electronic circuits. The brass contacts are gold plated to ensure excellent conductivity and corrosion resistance. It functions reliably across a temperature range from -55°C to 105°C, accommodating demanding industrial and commercial environments.

The Free Height series connectors enable stacking heights from 5 mm to 16 mm in 1 mm increments, allowing flexible vertical board arrangements to optimize space utilization. Its shrouded design protects contacts during handling and installation, while the solder termination ensures secure PCB mounting.

Applications include miniaturized electronic devices such as notebook PCs, pen pads, cellular phones, and other compact electronic equipment requiring space-saving, high-density interconnections. The mating system supports preloaded bellows-type spring contacts for reliable electrical contact.

This header supports a maximum voltage of 500V and current of 500mA. It is designed with brass contacts plated in gold for reliable conductivity and durability. The surface mount header operates between -55°C and 105°C for a wide range of applications.

The connector is shrouded and has a straight orientation with solder termination type. It enables parallel board stacking with high-density packaging, saving over 50% board space compared to conventional connectors. The male contact gender is suited for mating with corresponding receptacles.

Manufactured in China with a matt housing material for robust mechanical strength. Ideal for compact electronics such as notebooks, cellular phones, and miniaturized devices.
