Wurth Elektronik 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 2.2mH ±20% 530mA RDC 3.75Ω 7447709222
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Wurth Elektronik |
| Height | 10mm |
| Length | 12mm |
| Depth | 12mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 2.2mH |
| Standards/Approvals | REACH, RoHS, IEC 62024-2-2020, JEDEC JS709B |
| Package/Case | 1210 |
| Maximum DC Current | 530mA |
| Pin Count | 2 |
| Maximum DC Resistance | 3.75Ω |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 0.66MHz |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Features shielded construction with a ferrite core for improved performance.
- Designed for surface mount applications with a 1210 package size.
- Offers an inductance tolerance of ±20% and maximum DC resistance of 3.75Ω.
- Complies with automotive standard AEC-Q200, suitable for harsh environments.
- Designed to operate between -40°C and 125°C with a maximum self-resonant frequency of 0.66MHz.
- Encapsulated with moulded plastic for mechanical stability.
- Suitable for switching frequencies up to 10MHz in power supply circuits.
- Complies with REACH, RoHS, IEC 62024-2-2020, and JEDEC JS709B standards.
Product Description
Wurth Elektronik 7447709222 is a 1210 Shielded Wirewound Surface Mount Inductor featuring a high-quality ferrite core and an inductance of 2.2mH with ±20% tolerance. It is engineered for robust performance in demanding electronics applications, especially in power and passive component categories.
This inductor offers ultra-low DC resistance (RDC) of 3.75Ω, with a maximum DC current rating of 530mA, making it ideal for efficient power conversion and filtering in electronic circuits. Its shielded construction ensures minimal electromagnetic interference, enhancing signal integrity.
Designed for surface mount technology, it comes in a 1210 package size with dimensions approximately 12mm length, 10mm height, and 12mm depth. The component conforms to automotive grade AEC-Q200 standards, proving reliability in automotive and industrial conditions over an operating temperature range of -40°C to 125°C.
The inductor is moulded for increased mechanical stability and supports switching frequencies up to 10MHz, suitable for switch mode power supplies and DC-DC converters needing high efficiency and compact design. Compliance with REACH, RoHS, IEC 62024-2-2020, and JEDEC JS709B standards ensures environmental and safety adherence.
Manufactured in Thailand, this component is suitable for use across industrial, automotive, telecommunications, manufacturing, and electronic device applications requiring high efficiency and compact inductors with robust thermal and electrical features.
Shielded construction optimizes electromagnetic compatibility and performance. Ferrite core supports stable inductance in high-frequency applications. High operating temperature range from -40°C to 125°C for reliability in harsh environments.
AEC-Q200 automotive certification ensures quality for automotive electronics. Moulded package provides mechanical stability and durability. Low DC resistance improves energy efficiency and reduces thermal losses. Surface mount design suits compact PCB layouts and automated assembly.
Compliance with multiple international standards guarantees safety and performance. Explore more in the Surface Mount Inductors category on EnvMart for a wide range of electronic passive components designed for industrial and commercial electronics applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 2.2mH with an inductance tolerance of ±20%.
It has a maximum DC current rating of 530mA, making it suitable for various electronic applications.
This inductor has dimensions of approximately 12mm in length, 10mm in height, and 12mm in depth.
The maximum DC resistance (RDC) of this model is 3.75Ω, which contributes to its efficiency in power circuits.
It operates within a temperature range of -40°C to 125°C, suitable for harsh environments.
This inductor features a ferrite core, which supports stable inductance in high-frequency applications.
It complies with several standards, including REACH, RoHS, IEC 62024-2-2020, and JEDEC JS709B, ensuring safety and environmental adherence.
The maximum self-resonant frequency is 0.66MHz, making it suitable for high-frequency applications.
The termination style is surface mount, designed for compact PCB layouts and automated assembly.
This model meets the AEC-Q200 automotive standard, ensuring reliability in automotive electronics.
It is packaged in tape and reel format, facilitating easy handling and assembly in manufacturing processes.
It is suitable for applications in power supply circuits, switch mode power supplies, and DC-DC converters requiring high efficiency.
