Samtec TFM Series Straight Through Hole PCB Header, Shrouded, 60 Contacts, 1.27 mm Pitch, 2 Row, 250V, 3.2A TFM-130-01-S-D-RA

Samtec TFM-130-01-S-D-RA is a high-quality PCB Header from the TFM Series by Samtec. This straight through hole, shrouded connector features 60 gold-plated phosphor bronze contacts arranged in 2 rows with a 1.27 mm pitch. It is designed for wire-to-board applications requiring durability, reliability, and precision.

The housing is made of liquid crystal polymer, offering excellent mechanical strength and resistance to high temperatures ranging from -55°C to 125°C. Its robust multi-finger BeCu contact system ensures high reliability and supports high cycle mating, making it suitable for industrial and electronic manufacturing use cases.

The connector supports a current of 3.2A and a voltage rating of 250V, making it ideal for electronics requiring stable power and signal transmission. The shrouded body provides blind mating capability, reducing mating errors and mechanical damage.

Installation is via through-hole solder termination, thereby ensuring firm mechanical and electrical connections to PCB boards. The design also includes special rugged features such as screw down, weld tab, and solder nail options to meet demanding application needs.

This PCB header is widely used in industrial electronic components, electrical assemblies, manufacturing automation, communication equipment, and control systems. It is compatible with Tiger Eye™ contact sockets and cable assemblies for optimized performance.

Constructed with phosphor bronze contacts plated with gold for excellent conductivity. Features a liquid crystal polymer housing for durability and high temperature resistance. Designed with 2 rows and a 1.27 mm pitch for compact yet reliable connections.

Operates safely up to 250 volts and 3.2 amperes current capacity. Shrouded design supports blind mating and prevents misalignment. Suitable for high cycle applications with rugged multi-finger BeCu contact system. Supports through-hole solder termination ensuring strong mechanical and electrical connections.

Wide operating temperature range from -55°C to 125°C enhances versatility in diverse environments. Includes special features like screw down, weld tab, and solder nail options for enhanced rugged applications. Compatible with Tiger Eye™ contact sockets and cable assemblies for reliable mating.
