Samtec TFML Series 14 Contact Straight Through Hole PCB Header, 1.27 mm Pitch, 2 Row, Shrouded TFML-107-01-L-D-A-P

Free Delivery in India | Lowest Global Shipping Charges

Samtec TFML Series 14 Contact Straight Through Hole PCB Header, 1.27 mm Pitch, 2 Row, Shrouded TFML-107-01-L-D-A-P

Name: Samtec TFML Series 14 Contact Straight Through Hole PCB Header, 1.27 mm Pitch, 2 Row, Shrouded TFML-107-01-L-D-A-P
Brand: Samtec
SKU: 162826
Price: 3.1 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Samtec
Orientation	Straight
Current	3.2A
Model	TFML-107-01-L-D-A-P
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TFML
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	14
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board

Key Features

Features 14 male contacts arranged in 2 rows.
Uses gold-plated phosphor bronze contacts for reliable conductivity.
Housing molded from black liquid crystal polymer for insulation.
Operates within temperature range of -55°C to 125°C.
Designed for through hole mounting on PCBs.
Supports a current rating of 3.2A per contact pin.
Rated for up to 250V operating voltage.
1.27 mm pitch and row pitch ensure compact and precise placement.

Product Description

Samtec TFML-107-01-L-D-A-P is a high-reliability straight through hole PCB header from the TFML series designed for board-to-board connections. It features 14 gold-plated male contacts arranged in 2 rows with a precise 1.27 mm pitch. The black liquid crystal polymer housing provides excellent insulation and mechanical strength, suitable for demanding industrial and electronic applications.

This PCB header supports a current rating of 3.2A per pin and an operating voltage up to 250V, making it ideal for power and signal connections. The temperature range from -55°C to 125°C allows usage in various environmental conditions.

The connector system is shrouded to enhance the mechanical stability and electrical reliability in PCB assemblies. The solder termination type is compatible with standard PCB soldering processes ensuring easy and secure mounting.

Typical applications include industrial electronics, power connectors, instrumentation, control systems, and telecommunications. This product complies with no specific certifications but follows standard quality manufacturing practices to ensure durability and performance.

Features 14 male contacts for robust electrical connection. Gold plating on phosphor bronze contacts provides excellent conductivity and corrosion resistance. Black liquid crystal polymer insulating housing for mechanical and thermal stability.

Designed for use in board-to-board connector systems with shrouded protection. Suitable for operating temperatures between -55°C and 125°C. Solder termination type for permanent PCB installation. Rated for 3.2A current and 250V voltage for versatile electronic applications.

Ensures precise positioning with 1.27 mm contact and row pitch. Ideal for industrial fabrication and electronic assembly environments. Explore more PCB Headers and connectors in the Electronics & Electricals category on EnvMart for reliable and precision electronic components.
