Samtec TSW Series Straight Through Hole Pin Header, 10 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-105-15-G-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.3A |
| Model | TSW-105-15-G-D |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.79mm |
| Mating Pin Length | 13.21mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Designed for board-to-board connection systems using through-hole mounting.
- Features a current rating of 4.3A with 550V voltage handling capacity.
- Constructed with polybutylene terephthalate housing and phosphor bronze contacts plated in gold.
- Operates reliably within a temperature range of -55°C to 125°C.
- Pin length measures 13.21 mm with a tail pin length of 2.79 mm for solder termination.
- Unshrouded male contact pins arranged in two rows with a 2.54 mm row pitch.
- Offers multiple plating and ruggedizing options for cost optimization and performance.
Product Description
Samtec TSW-105-15-G-D is a high-quality straight through hole pin header designed for electronic applications requiring reliable board-to-board connection. This connector features 10 male contacts arranged in two rows with a precise 2.54 mm pitch, ideal for vertical mounting on printed circuit boards (PCB).
The housing is made from robust polybutylene terephthalate material, ensuring durability and stability during operation. Contact pins crafted from phosphor bronze with gold plating offer excellent conductivity and corrosion resistance, supporting a rated current of 4.3 amperes and voltage capacity up to 550 volts.
Operating temperature ranges from -55°C to +125°C, allowing use in various industrial and commercial environments.
The termination method is via through-hole solder tails with a pin length of 13.21 mm and a tail pin length of 2.79 mm, facilitating secure PCB attachment. The connector's unshrouded design allows easy mating with other standard components and maximizes accessibility.
Applications for this pin header include electronic manufacturing, industrial controls, instrumentation, and other commercial electronic assemblies. The TSW series offers many options for customizing plating and ruggedizing features to optimize cost and durability according to specific project needs.
Designed for board-to-board connection using through-hole mounting. 10 male phosphor bronze contacts gold plated for superior conductivity. Polybutylene terephthalate housing ensures mechanical strength. Rated for 4.3A current and 550V voltage tolerance.
Wide operating temperature from -55°C to 125°C. Pin length 13.21 mm, tail pin length 2.79 mm for reliable solder termination. Unshrouded contact design with 2 rows at 2.54 mm pitch. Suitable for industrial, commercial, and electronic connector applications.
Explore the comprehensive range of Samtec PCB headers at EnvMart to find compatible components ideal for your electronic control and manufacturing needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 4.3A, making it suitable for various electronic applications.
It can handle a voltage of up to 550V, which is suitable for many industrial and commercial applications.
The pin header operates reliably within a temperature range of -55°C to +125°C, allowing for use in diverse environments.
This unit features a 2.54 mm pitch with 10 male contacts arranged in two rows, designed for board-to-board connections.
The housing is made from polybutylene terephthalate, while the contacts are phosphor bronze plated in gold for enhanced conductivity.
The pin length measures 13.21 mm, and the tail pin length is 2.79 mm, facilitating secure solder termination.
This connector features an unshrouded design, allowing for easy mating with other standard components.
It uses through-hole solder termination, which is standard for secure PCB attachment.
The TSW series offers many options for optimizing cost and performance with various platings and ruggedizing features.
It is suitable for electronic manufacturing, industrial controls, instrumentation, and other commercial electronic assemblies.
This product is manufactured in India, ensuring compliance with relevant quality standards.
The unshrouded male contact pins and through-hole mounting design maximize accessibility and ease of use in various electronic applications.
