Samtec TFM Series Straight Through Hole PCB Header, 20 Contacts, 1.27 mm Pitch, 2 Row, Shrouded TFM-110-02-S-D-A-K-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.2A |
| Model | TFM-110-02-S-D-A-K-TR |
| Mount Type | Through Hole |
| Special Features | Screw down, weld tab and solder nail options available for most rugged requirements |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TFM |
| Termination | Through-hole, surface mount |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Contact System | .018" (0.46 mm) diameter post |
Key Features
- Features a shrouded design for improved blind mating reliability.
- Designed with 2 rows of straight orientation contacts.
- Utilizes gold-plated phosphor bronze contacts for exceptional conductivity.
- Made from Liquid Crystal Polymer housing for durability and heat resistance.
- Rated at 3.2A current and 250V voltage capacity.
- Suitable for through-hole mounting with solder termination.
- Operates reliably between -55°C and 125°C.
- Includes special features such as screw down, weld tab, and solder nail options for rugged applications.
Product Description
Samtec TFM-110-02-S-D-A-K-TR is a high-reliability PCB Header designed for electronic component interconnection with precise specifications. This through-hole mount header features 20 male contacts arranged in 2 rows with a pitch of 1.27 mm, supporting current up to 3.2 amperes and voltage ratings of 250 volts. The housing is made from Liquid Crystal Polymer, providing excellent thermal and mechanical robustness.
The contact system uses gold-plated phosphor bronze contacts to ensure superior electrical conductivity and long life. Its shrouded body enables secure blind mating, enhancing mechanical stability during assembly and operation. The header operates efficiently within a wide temperature range from -55°C to 125°C, making it suitable for demanding industrial, manufacturing, and electronic assembly applications.
This rugged component supports wire-to-board connections and is terminated by soldering. Its special features include options for screw down, weld tab, and solder nail terminations to meet the needs of the most challenging rugged environments. The product is well-suited for use in industrial control systems, automation equipment, instrumentation, communications hardware, and other applications requiring durable and reliable PCB connectors.
Features a shrouded design for improved blind mating reliability. Designed with 2 rows of straight orientation contacts. Utilizes gold-plated phosphor bronze contacts for exceptional conductivity. Made from Liquid Crystal Polymer housing for durability and heat resistance.
Rated at 3.2A current and 250V voltage capacity. Suitable for through-hole mounting with solder termination. Operates reliably between -55°C and 125°C. Includes special features such as screw down, weld tab, and solder nail options for rugged applications.
Ideal for wire-to-board connection in industrial and electronic devices. Explore EnvMart's wide range of PCB Headers and high-quality electronic components to find compatible parts and accessories to complete your assembly and manufacturing projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3.2A and a voltage of 250V.
It features a pitch of 1.27 mm and has 20 male contacts arranged in 2 rows.
The housing is made from Liquid Crystal Polymer, while the contacts are constructed from gold-plated phosphor bronze.
It operates reliably within a temperature range of -55°C to 125°C.
This unit is designed for through-hole mounting with solder termination.
It includes options for screw down, weld tab, and solder nail terminations, making it suitable for rugged applications.
The connector system is designed for wire-to-board connections.
The contact system features a post diameter of .018" (0.46 mm).
Yes, it is well-suited for use in industrial control systems, automation equipment, and other demanding electronic assembly applications.
The contacts are arranged in a straight orientation.
The country of origin for this model is India.
It uses solder termination for secure connections.
