Samtec SSM Series Straight Surface PCB Socket, 18-Contact, 2 Row, 2.54 mm Pitch, 5.2A, 572V SSM-109-L-DV
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 572V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 5.2A |
| Model | SSM-109-L-DV |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | SSM |
| Termination | Surface mount |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 18 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Contact System | Tiger Claw™ |
| Row Pitch | 2.5mm |
Key Features
- Constructed with a liquid crystal polymer housing for durability.
- Designed for surface mount termination and board-to-board connection.
- Features a Tiger Claw™ contact system ensuring reliable signal integrity.
- Suitable for operating temperatures from -55°C to 125°C.
- Contact material is bronze with gold plating for enhanced conductivity and corrosion resistance.
- Supports a voltage rating of 572V for diverse applications.
- Orientation is straight with female contact gender.
- Ideal for electronic components requiring compact and reliable PCB socket connections.
Product Description
The Samtec SSM-109-L-DV is a straight surface PCB socket from the SSM Series, designed for high-performance board-to-board connections in electronic assemblies. This product features 18 contacts arranged in two rows with a precise 2.54 mm pitch suitable for various industrial and commercial electronics applications.
Manufactured with a durable liquid crystal polymer housing, the socket supports a current rating of 5.2A and a maximum voltage of 572V, ensuring safe and efficient electrical performance. The Tiger Claw™ contact system provides excellent reliability and consistent electrical contact, making it ideal for demanding environments.
The socket is designed for surface mount solder termination and has a straight orientation with female contact gender, facilitating compatibility with a wide range of PCB layouts. Operating temperature ranges from -55°C to 125°C, making it suitable for harsh conditions encountered in industrial, laboratory, and manufacturing setups.
Contact components are made of bronze with gold plating, enhancing conductivity and preventing corrosion. This makes the socket robust for long-term use in electronics requiring precision and high reliability.
The product is widely used in electronics prototyping, testing, and production where a compact, reliable connector solution is essential. Its compatibility with single and double-row configurations up to 80 pins offers versatile application potential.
Constructed with liquid crystal polymer housing for durability and thermal stability. Features a Tiger Claw™ contact system for secure electrical connections. Supports 18 contacts in 2 rows with 2.54 mm pitch spacing. Resistant to temperature extremes from -55°C to 125°C.
Gold plated bronze contacts for corrosion resistance and conductivity. Rated for 5.2A current and 572V voltage applications. Surface mount termination with straight orientation and female contacts. Ideal for electronics manufacturing, testing, and industrial usage.
Compatible with a variety of PCB socket requirements in board-to-board configurations.
Explore our extensive range of PCB Sockets and electronic components at EnvMart for reliable connectivity solutions tailored for industrial, commercial, and laboratory electronic assemblies.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating of this PCB socket is 572V, making it suitable for a variety of applications requiring high voltage connections.
This model supports a current rating of 5.2A, ensuring efficient electrical performance in various applications.
The housing of this socket is constructed from liquid crystal polymer, which provides durability and thermal stability.
The SSM-109-L-DV features 18 contacts arranged in two rows, with a pitch of 2.54 mm.
It operates within a temperature range of -55°C to 125°C, making it suitable for harsh environmental conditions.
This socket utilizes surface mount termination with solder, facilitating easy integration into PCB designs.
The contact gender of this model is female, allowing it to connect with compatible male connectors in board-to-board configurations.
It features a Tiger Claw™ contact system, which ensures reliable signal integrity and secure electrical connections.
The pitch size of the contacts is 2.54 mm, which is standard for many electronic applications.
The contacts are made of bronze with gold plating, which enhances conductivity and provides corrosion resistance.
This socket is ideal for electronics manufacturing, testing, and industrial usage, particularly in board-to-board connections.
The orientation of this PCB socket is straight, which aids in compatibility with various PCB layouts.
