Samtec SSM Series Straight Surface PCB Socket, 9-Contact, 1 Row, 2.54 mm Pitch, 5.2A Current, 572V Voltage SSM-109-L-SV
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 572V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 5.2A |
| Model | SSM-109-L-SV |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | SSM |
| Termination | Surface mount |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 9 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Contact System | Tiger Claw™ |
Key Features
- Constructed with a Liquid Crystal Polymer housing for durability and thermal stability.
- Supports a maximum current of 5.2 amperes and voltage rating of 572 volts.
- Features Tiger Claw™ contact system with gold-plated bronze female contacts for reliable connectivity.
- Operates within temperature range of -55°C to 125°C ensuring broad environmental performance.
- Designed for surface mount termination on PCBs in board-to-board connector applications.
- Compatible with single and double row configurations up to 80 pins.
- Manufactured in the United States with a focus on precision and quality.
Product Description
Samtec SSM-109-L-SV is a straight orientation surface mount PCB Socket from the SSM series, designed for electronic component assembly in industrial and manufacturing applications. Incorporating 9 contacts arranged in a single row with a 2.54 mm pitch, this connector supports current up to 5.2 A and voltage ratings of 572 V, suitable for reliable electrical connections in demanding environments.
The connector features a housing made from Liquid Crystal Polymer, known for its high mechanical strength and thermal resistance, allowing operation over a wide temperature range from -55°C to 125°C. Its contacts are bronze plated with gold, enhancing corrosion resistance and conductivity, and utilizing the patented Tiger Claw™ contact system to ensure consistent mating force and low contact resistance.
Surface mounting termination and straight orientation make the SSM-109-L-SV ideal for board-to-board interconnections in electronic devices, controlling signal integrity and mechanical stability. It is applicable for industrial electronics, automation systems, telecommunications equipment, and other electronic assemblies requiring durable and precise connectivity.
Constructed with Liquid Crystal Polymer housing providing mechanical strength and thermal stability. Supports 5.2 A current rating and 572 V voltage for robust electrical performance. Incorporates Tiger Claw™ contact system for consistent and reliable electrical contact.
Gold-plated bronze female contacts improve conductivity and corrosion resistance. Operates within a temperature range from -55°C to 125°C suitable for harsh environments. Designed for surface mount PCB assembly in board-to-board connector systems.
Manufactured in the United States ensuring high quality and precision.
This SSM series socket provides essential connectivity solutions for electronics manufacturing, prototyping, and repair activities. It aligns with industrial quality standards without additional certifications specified. Explore related PCB Sockets and connectors in the Electronics Components category at EnvMart for comprehensive solutions in electronic assembly and maintenance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 5.2 amperes.
The SSM-109-L-SV has a voltage rating of 572 volts.
The contacts in this socket are arranged with a pitch of 2.54 mm.
The housing of this unit is constructed from Liquid Crystal Polymer, providing durability and thermal stability.
It incorporates the Tiger Claw™ contact system, which ensures consistent mating force and low contact resistance.
The SSM-109-L-SV operates within a temperature range of -55°C to 125°C.
This model features 9 female contacts arranged in a single row.
It is designed for surface mount termination, specifically solder termination.
This socket has a straight orientation, suitable for board-to-board connections.
The contacts are made of bronze and are gold-plated to enhance conductivity and corrosion resistance.
This model is manufactured in the United States, ensuring high quality and precision.
It is applicable for industrial electronics, automation systems, telecommunications equipment, and other electronic assemblies requiring reliable connectivity.
