Samtec SSM Series Straight Surface PCB Socket, 50-Contact, 2 Row, 2.54 mm Pitch, Surface Mount SSM-125-L-DV-LC
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 572V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 5.2A |
| Model | SSM-125-L-DV-LC |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Current Rating | 5.2A per pin(2 pins powered) |
| Series | SSM |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 50 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Row Pitch | 2.5mm |
| Normal Force | 125grams (1.21N) average |
Key Features
- Constructed with liquid crystal polymer housing for high durability.
- Contacts are female, made from phosphor bronze with gold plating for reliable conductivity.
- Rated for 5.2A current per pin with 405VAC/572VDC voltage rating.
- Operates in temperatures from -55°C to 125°C ensuring reliability in varied environments.
- Designed with tiger claw contact style providing firm connection and average normal force of 125 grams.
- Board-to-board connector system suitable for electronic component interconnection.
- Surface mount termination allows for compact PCB assembly.
- Series SSM ensures compatibility and quality standards.
Product Description
Samtec SSM-125-L-DV-LC is a straight surface PCB socket designed for board-to-board connectivity applications. It provides 50 female contacts arranged in 2 rows with a 2.54 mm pitch, making it suitable for compact and precise electronic circuit assemblies. The socket features a robust liquid crystal polymer housing which offers excellent mechanical strength and thermal stability.
The contact material is phosphor bronze with gold plating, ensuring low contact resistance and reliable electrical performance. Each pin supports a current rating of up to 5.2 amperes with a voltage rating of 572 volts DC / 405 volts AC, suitable for moderate power electronic applications.
Operating temperature ranges from -55°C to 125°C, enabling usage in demanding industrial and commercial environments. The connector employs a tiger claw contact design which provides good retention force with an average normal force of 125 grams, ensuring consistent contact pressure and signal integrity.
Termination is surface mount style, optimizing the socket for automated PCB assembly processes without compromising the socket durability. It is part of the SSM series from Samtec, known for its quality and standard compliance.
This PCB socket is ideal for industrial electronics, manufacturing, assembly, and maintenance of board-to-board connector systems in various sectors including industrial control, instrumentation, and communication devices.
Constructed with liquid crystal polymer housing for high durability. Contacts are female, made from phosphor bronze with gold plating for reliable conductivity. Rated for 5.2A current per pin with 405VAC/572VDC voltage rating.
Operates in temperatures from -55°C to 125°C ensuring reliability in varied environments. Designed with tiger claw contact style providing firm connection and average normal force of 125 grams. Board-to-board connector system suitable for electronic component interconnection.
Surface mount termination allows for compact PCB assembly. Series SSM ensures compatibility and quality standards. Explore more high-quality PCB Sockets and related components in our Electronics & Electricals catalog at EnvMart.
