Samtec HTSW Series Right Angle Through Hole Pin Header, 3 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded HTSW-103-08-G-S-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 400, 450, 500, 550V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 4.3A |
| Model | HTSW-103-08-G-S-RA |
| Mount Type | Through Hole |
| Special Features | Suitable for most high-temperature board processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | HTSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.29mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Supports a current rating of 4.3 amperes for robust electrical performance.
- Constructed with Liquid Crystal Polymer housing for high-temperature resistance.
- Features gold-plated phosphor bronze contacts to ensure conductivity and corrosion resistance.
- Compact 1-row configuration with right-angle orientation for versatile PCB layouts.
- Unshrouded design suitable for solder termination through-hole mounting.
- Operates in temperatures from -55°C up to 125°C to withstand harsh environments.
- Tail pin length of 2.29 mm and mating pin length of 5.84 mm for secure connections.
- Contact system utilizes 0.025 inch (0.635 mm) square posts for secure contact engagement.
Product Description
Samtec HTSW-103-08-G-S-RA is a high-quality right angle through hole pin header designed for board-to-board connections in electronic assemblies. This connector features 3 male contacts arranged in a single row with a standard 2.54 mm pitch, making it compatible with a wide range of PCBs and electronic components.
The housing is made from Liquid Crystal Polymer, providing exceptional durability and stability in high-temperature environments. Gold-plated phosphor bronze contacts ensure optimal electrical conductivity and resistance to corrosion, suitable for long-term use in demanding industrial and commercial applications.
Rated for currents up to 4.3 amperes and voltages ranging from 400 to 550 volts, this pin header supports reliable high-performance operation. Its right-angle orientation and unshrouded design facilitate easy mounting and soldering through the PCB, offering flexibility in circuit layout and assembly processes.
The connector operates effectively within a temperature range of -55°C to 125°C, suitable for industrial, laboratory, manufacturing, and electronic assembly environments. The contact system uses 0.025 inch (0.635 mm) square posts, providing secure mating connections. Tail pins measure 2.29 mm in length, with mating pins extending to 5.84 mm to ensure solid engagement.
Samtec's HTSW series is recognized for its high-temperature processing suitability and reliability in various electronic component applications. This part is ideal for engineers and manufacturers requiring precise and durable PCB connectors.
Supports 4.3A current rating. Housing material is Liquid Crystal Polymer. Gold-plated phosphor bronze contacts. Right angle orientation, single row with 3 contacts. Unshrouded, through-hole mount. Operative temperature range from -55°C to 125°C.
Voltage rating up to 550V. Contact system uses 0.025 inch square posts. Tail pin length 2.29 mm, mating pin length 5.84 mm. Explore Samtec HTSW series connectors and other PCB header solutions at EnvMart for professional electronics assembly needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 4.3 amperes, ensuring robust electrical performance.
It has a voltage rating ranging from 400 to 550 volts, suitable for various applications.
The housing is constructed from Liquid Crystal Polymer, providing high-temperature resistance.
It features gold-plated phosphor bronze contacts, which ensure conductivity and corrosion resistance.
The contact pitch is 2.54 mm, making it compatible with a wide range of PCBs.
The tail pin length is 2.29 mm, while the mating pin length is 5.84 mm, ensuring secure connections.
It operates effectively within a temperature range of -55°C to 125°C, suitable for harsh environments.
This unit is designed for through-hole mounting, allowing for solder termination.
It features a right-angle orientation, which provides flexibility in PCB layout.
This pin header has 3 male contacts arranged in a single row.
Yes, it is suitable for most high-temperature board processing, making it ideal for demanding applications.
It utilizes a board-to-board connector system, which is common in electronic assemblies.
