Samtec IPL1 Series Straight Surface PCB Header, 4 Contacts, 2.54 mm Pitch, 2 Rows, Shrouded IPL1

Samtec IPL1 Series Straight Surface PCB Header IPL1 is a high-quality electronic component designed for wire-to-board interconnections. Featuring a 2.54 mm pitch and 4 contacts arranged in 2 rows, this header offers reliable electrical performance with a shrouded design for secure connections.

The housing material is Liquid Crystal Polymer, providing excellent resistance to heat and mechanical stress, making it ideal for demanding industrial and electronic manufacturing environments. The phosphor bronze contact material plated with tin ensures electrical conductivity and corrosion resistance.

Current rating is 3.8A at 95°C, supporting moderate power loads in PCB applications. The header is designed for surface mounting with a solder termination type, simplifying PCB assembly processes. Operating temperature ranges from -55°C to 125°C, accommodating a wide variety of environmental conditions.

This straight orientation header suits vertical mounting with a standardized 2.54 mm row pitch, perfect for many PCB designs requiring secure and compact wire-to-board connectivity.

The housing is made from Liquid Crystal Polymer to withstand high temperatures. Rated for 3.8A current at 95°C operating temperature. Phosphor bronze contacts with tin plating provide durability and conductivity. Surface mount design with solder termination for easy assembly.

Supports operation in temperatures from -55°C to 125°C. Voltage rating of 954V for demanding industrial applications. Shrouded male contacts ensure reliable connections. Ideal for applications in electronics manufacturing, industrial control systems, telecommunications, and other sectors requiring robust PCB connectivity solutions.

Samtec IPL1 Series provides designers and assemblers with a trusted, durable solution for PCB Header requirements.
