Samtec IPBS Series Straight Through Hole PCB Socket, 4-Contact, 2 Row, 4.19 mm Pitch, 5.3A, 565V, Liquid IPBS-102-01-T-D
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 565V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 5.3A |
| Model | IPBS-102-01-T-D |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | IPBS |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 4.19mm |
| Standards/Approvals | RoHS |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket features a liquid crystal polymer housing ensuring durability and high performance.
- Designed for through hole mounting with solder termination type.
- It supports a current rating of 5.3 amperes and voltage rating of 565 volts.
- The contacts are made of bronze with tin plating, offering reliable conductivity.
- Operating temperature ranges from -55°C to 105°C for versatile environments.
- Connector orientation is straight with female contact gender suitable for board-to-board connection systems.
- The product complies with RoHS standards for environmental safety.
- Originates from the United States, ensuring quality manufacturing standards.
Product Description
Samtec IPBS-102-01-T-D is a high-quality PCB Socket from the IPBS Series designed as a straight through hole connector with 4 contacts arranged in 2 rows and a pitch of 4.19 mm. It uses a robust liquid crystal polymer housing material which provides excellent mechanical stability and resistance to high temperatures.
With a current rating of 5.3 A and voltage rating of 565 V, this socket supports demanding electrical applications, making it suitable for electronics manufacturing, industrial board assembly, and maintenance tasks requiring reliable board-to-board connections.
The connector features bronze contacts with tin plating to ensure efficient electrical conductivity and corrosion resistance. Its female contact gender and straight orientation support seamless connection integration in various PCB layouts.
Operating temperatures range from -55°C to 105°C, allowing this PCB socket to perform reliably in a wide array of industrial, commercial, and laboratory environments. The through hole mounting and solder termination type make it compatible with conventional PCB assembly processes.
This component complies with RoHS environmental standards, ensuring it is free from hazardous substances. Manufactured in the United States, it follows stringent quality controls expected in high-standard electronics production.
The socket has 4 contacts arranged in 2 rows. Pitch between contacts is 4.19 mm. Current rating up to 5.3 A. Voltage withstand up to 565 V. Contacts made of bronze, plated with tin. Housing material is liquid crystal polymer.
Operating temperature range is -55°C to 105°C. Compliance with RoHS environmental safety directive.
Ideal for electronics manufacturing, laboratory equipment, industrial automation, and electronic repair markets. Explore full listings of PCB Sockets and connectors at EnvMart for precise component matching and sourcing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 5.3 amperes, making it suitable for demanding electrical applications.
The voltage rating for the IPBS-102-01-T-D is 565 volts, allowing it to handle high-voltage applications.
It features through hole mounting with a solder termination type, compatible with conventional PCB assembly processes.
The pitch between contacts is 4.19 mm, which is essential for ensuring proper alignment in PCB layouts.
The housing is made from liquid crystal polymer, while the contacts are bronze with tin plating for reliable conductivity.
This model operates effectively within a temperature range of -55°C to 105°C, suitable for various environments.
The connector orientation is straight, designed for seamless integration in board-to-board connection systems.
This socket has a total of 4 contacts arranged in 2 rows, facilitating multiple connection points.
Yes, it complies with RoHS standards, ensuring it is free from hazardous substances.
It supports a board-to-board connector system, making it suitable for various electronic applications.
This product originates from the United States, ensuring adherence to quality manufacturing standards.
The contact gender is female, which is standard for board-to-board connections.
