Molex Mini-Fit Jr Series Straight Through Hole PCB Header 10 Contact 4.2 mm Pitch 2 Row Shrouded 39-29-3106

Molex 39-29-3106 Mini-Fit Jr Series straight through hole PCB header is a high-quality wire-to-board connector designed for electronic and industrial applications. Featuring 10 male contacts arranged in two rows with a 4.2 mm pitch, this shrouded header ensures reliable mating and electrical performance.

The housing is constructed from nylon material, providing robust mechanical stability and electrical insulation. Tin-plated brass contacts offer excellent conductivity and resistance to corrosion, ideal for power distribution circuits.

This PCB header supports a maximum current of 9 A and voltage of 600 V, making it suitable for portable, handheld, and power equipment requiring durable connectivity.

Operating temperature range from -40°C to 125°C enables use in varying environmental conditions. The solder termination with 3.5 mm tail pin length facilitates secure attachment to the PCB board, ensuring mechanically sound connections.

The dual-row, straight orientation along with the shrouded design improves connection reliability, reduces the chance of misalignment, and protects contacts during installation.

This product is manufactured in Mexico to meet international quality standards. It is widely applicable in industrial electronics, power supplies, and communication equipment requiring dependable PCB connections.

This PCB header features a dual row with 10 male contacts for stable electrical connection. It has a pitch size of 4.2 mm designed for through hole mounting on PCB. The housing is made from durable nylon material ensuring electrical insulation.

Contacts are tin-plated brass providing corrosion resistance and good conductivity. The header is shrouded to enhance connector protection and alignment. It supports a current rating up to 9 A and a voltage rating of 600 V suitable for power applications.

Operating temperature ranges from -40°C to 125°C supporting harsh environments. Termination type is via solder tail pins with a length of 3.5 mm for soldering on PCB. It provides a straight orientation for easy cable routing and assembly.

Made in Mexico offering consistent quality manufacturing standards. Explore more high-quality PCB connectors and headers at EnvMart for your electronics manufacturing and repair needs.
