TE Connectivity Dubox Series Straight Through Hole PCB Header, 8 Contacts, 2.54 mm Pitch, 1 Row, Shrouded, Glass 76384-308LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1kV |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 3A |
| Model | 76384-308LF |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Thermoplastic |
| Contact Material | Phosphor Bronze |
| Series | Dubox |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 0.62mm |
Key Features
- The header is shrouded on two walls to protect contacts and ensure mating accuracy.
- Constructed with glass filled thermoplastic housing for high temperature resistance during soldering.
- Contact material is phosphor bronze with gold plating for excellent conductivity and corrosion resistance.
- Supports current ratings up to 3A and voltage up to 1kV, suitable for demanding electrical applications.
- Designed with polarization and friction lock to prevent mismating and ensure secure connection.
- Through hole mount type with straight orientation for PCB assembly.
- Operational temperature ranges from -65°C to 125°C ensuring robustness in various environments.
Product Description
Amphenol Communications Solutions 76384-308LF Dubox Series Straight Through Hole PCB Header is a high-quality, shrouded header connector designed for industrial and commercial wire-to-board applications. This PCB header features 8 individual contacts arranged in a single row with a 2.54 mm pitch, suitable for compact and space-saving PCB designs.
The connector housing is constructed from glass filled thermoplastic, providing excellent durability and the ability to withstand the heat of solder reflow and wave solder processes. The phosphor bronze contacts are gold plated to provide reliable electrical performance, resistance to corrosion, and long service life.
This Dubox Series header ensures secure mating thanks to its polarization features that prevent incorrect assembly and a friction lock that ensures the connector remains securely engaged. It is designed with a straight orientation and through-hole mount style for stable and easy PCB integration.
The header supports a maximum current of 3A and can operate efficiently at voltages up to 1kV. Its operational temperature range from -65°C to 125°C enables it to be used in harsh environments including industrial, instrumentation, communications, medical, and consumer electronics sectors.
The shrouded design safeguards contacts against damage and contamination. High temperature resistant housing material supports soldering processes. Reliable electrical connections with gold plated phosphor bronze contacts.
Polarization to prevent mismating and friction lock for a secure fit. Compatible with Dubox crimp connector housings for wire-to-board interconnections. Ideal for various markets including industrial and medical applications.
Amphenol Communications Solutions provides a trusted and efficient Dubox Series interconnection system that promotes design flexibility and reliability in electronic assemblies. Explore more products in the PCB Headers category on EnvMart for diverse options in connector technology.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current rating of 3A.
It can operate efficiently at voltages up to 1kV.
The housing is made of glass filled thermoplastic, while the contacts are made from phosphor bronze with gold plating.
The contacts are arranged with a pitch of 2.54 mm.
It operates within a temperature range of -65°C to 125°C.
This header features 8 individual contacts.
It utilizes a solder termination type.
This model has a straight orientation.
It is a shrouded header, designed to protect contacts and ensure mating accuracy.
This header is designed for a wire-to-board connector system.
It includes polarization features and a friction lock to prevent mismating and ensure a secure connection.
The country of origin for this product is France.
