Samtec TSW Series Straight Through Hole Pin Header 10 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-110-15-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-110-15-T-S |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- The connector has a pitch of 2.54 mm enabling standard spacing for PCB mounting.
- Features 10 gold-plated phosphor bronze male contacts for reliable conductivity.
- Constructed with a glass-filled polyester housing material ensuring durability.
- Designed as a through-hole mount type with straight orientation for easy solder termination.
- Operational temperature range from -55°C to 125°C suitable for harsh environments.
- Rated for 550 V voltage handling capacity ensuring electrical robustness.
- Termination type is solder ensuring strong mechanical and electrical connection to PCB.
- The connector system is board-to-board with an unshrouded profile for flexible mating options.
Product Description
Samtec TSW-110-15-T-S is a high-quality straight through hole pin header designed for secure board-to-board connections in industrial electronics. Featuring 10 male contacts with a 2.54 mm pitch in a single row, this component supports applications requiring reliable electrical connection and durability.
The housing is made from glass-filled polyester, providing mechanical strength and resistance to environmental stresses. Contacts are made of phosphor bronze plated with gold to ensure excellent conductivity and corrosion resistance. The through-hole solder termination ensures a firm, long-lasting attachment to PCBs.
It operates reliably within a temperature range from -55°C to 125°C and can handle voltages up to 550 V, making it suitable for demanding industrial, communication, and computing equipment applications.
The connector features a .025" square post contact system in an unshrouded design, allowing flexible mating with complementary connectors. Samtec's TSW series is known for its extended life performance, passing 10-year Mixed Flowing Gas (MFG) tests and supporting mating cycles from 250 to 2,500, ideal for high-reliability use cases.
The connector pitch of 2.54 mm is industry-standard for many PCB layouts. Gold-plated phosphor bronze contacts ensure consistent electrical performance. Glass-filled polyester housing offers durability and heat resistance.
Through-hole solder termination provides robust mechanical connection. Suitable for industrial, communication, and computing applications. Temperature range compatible with harsh environment operations. Voltage rating supports demanding electrical systems.
Unshrouded design allows for easy integration with board-to-board systems. Extended life product with high mating cycle endurance. Single row layout simplifies design and assembly.
This Samtec pin header is a reliable component choice for electronics manufacturers and engineers designing robust PCBs for industrial, manufacturing, and commercial applications. Explore the wide selection of PCB Headers on EnvMart for matched components and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.54 mm, which is a standard spacing for PCB mounting.
This model features 10 male contacts, providing reliable electrical connections.
It is rated for a maximum voltage of 550 V, ensuring electrical robustness for various applications.
The housing is made from glass-filled polyester, while the contacts are made of phosphor bronze with gold plating for enhanced conductivity.
The operational temperature range is from -55°C to 125°C, making it suitable for harsh environments.
This pin header uses a through-hole solder termination type, ensuring a strong mechanical and electrical connection to PCBs.
It features a straight orientation, which facilitates easy solder termination during assembly.
The TSW-110-15-T-S is designed as an unshrouded connector, allowing for flexible mating options with complementary connectors.
It supports a board-to-board connector system, making it suitable for various electronic applications.
The contact system features a .025" (0.635 mm) square post design, which is common in many PCB applications.
The country of origin for this pin header is India.
This model is part of the Samtec TSW series, known for its extended life performance and reliability in various applications.
